#include <Service_Gestalt.h>
Public Types | |
enum | { MAX_SERVICES = ACE_DEFAULT_SERVICE_REPOSITORY_SIZE } |
Public Member Functions | |
ACE_Service_Gestalt (size_t size=1024, bool svc_repo_is_owned=true, bool no_static_svcs=true) | |
virtual | ~ACE_Service_Gestalt (void) |
void | dump (void) const |
Dump the state of an object. | |
int | open (const ACE_TCHAR program_name[], const ACE_TCHAR *logger_key=ACE_DEFAULT_LOGGER_KEY, bool ignore_static_svcs=true, bool ignore_default_svc_conf_file=false, bool ignore_debug_flag=false) |
int | open (int argc, ACE_TCHAR *argv[], const ACE_TCHAR *logger_key=ACE_DEFAULT_LOGGER_KEY, bool ignore_static_svcs=true, bool ignore_default_svc_conf_file=false, bool ignore_debug_flag=false) |
int | is_opened (void) |
int | process_directive (const ACE_TCHAR directive[]) |
int | process_directive (const ACE_Static_Svc_Descriptor &ssd, bool force_replace=false) |
Process one static service definition. | |
int | process_file (const ACE_TCHAR file[]) |
int | find (const ACE_TCHAR name[], const ACE_Service_Type **srp=0, int ignore_suspended=1) const |
Searches for a service object declaration in the local repo, only. | |
int | parse_args (int, ACE_TCHAR *argv[]) |
int | process_directives (bool ignore_default_svc_conf_file) |
int | close (void) |
int | insert (ACE_Static_Svc_Descriptor *stsd) |
int | initialize (const ACE_Service_Type_Factory *, const ACE_TCHAR *parameters) |
int | initialize (const ACE_Service_Type *, const ACE_TCHAR *parameters) |
int | initialize (const ACE_TCHAR *svc_name, const ACE_TCHAR *parameters) |
Initialize and activate a statically svc_name service. | |
int | resume (const ACE_TCHAR svc_name[]) |
int | suspend (const ACE_TCHAR svc_name[]) |
int | remove (const ACE_TCHAR svc_name[]) |
int | find_static_svc_descriptor (const ACE_TCHAR *name, ACE_Static_Svc_Descriptor **ssd=0) const |
Find a static service descriptor by name. | |
ACE_Service_Repository * | current_service_repository (void) |
Get the current ACE_Service_Repository held by this object. | |
Static Public Member Functions | |
static void | intrusive_add_ref (ACE_Service_Gestalt *) |
static void | intrusive_remove_ref (ACE_Service_Gestalt *) |
Public Attributes | |
ACE_ALLOC_HOOK_DECLARE | |
Declare the dynamic allocation hooks. | |
Protected Types | |
typedef ACE_Unbounded_Queue < ACE_TString > | ACE_SVC_QUEUE |
typedef ACE_Unbounded_Queue_Iterator < ACE_TString > | ACE_SVC_QUEUE_ITERATOR |
typedef ACE_Unbounded_Set < ACE_Static_Svc_Descriptor * > | ACE_STATIC_SVCS |
typedef ACE_Unbounded_Set_Iterator < ACE_Static_Svc_Descriptor * > | ACE_STATIC_SVCS_ITERATOR |
typedef ACE_Unbounded_Set < Processed_Static_Svc * > | ACE_PROCESSED_STATIC_SVCS |
typedef ACE_Unbounded_Set_Iterator < Processed_Static_Svc * > | ACE_PROCESSED_STATIC_SVCS_ITERATOR |
Protected Member Functions | |
virtual int | parse_args_i (int, ACE_TCHAR *argv[], bool &ignore_default_svc_conf_file) |
virtual int | open_i (const ACE_TCHAR program_name[], const ACE_TCHAR *logger_key=ACE_DEFAULT_LOGGER_KEY, bool ignore_static_svcs=true, bool ignore_default_svc_conf_file=false, bool ignore_debug_flag=false) |
int | init_svc_conf_file_queue (void) |
Initialize the <svc_conf_file_queue_> if necessary. | |
int | load_static_svcs (void) |
int | process_commandline_directives (void) |
int | process_directive_i (const ACE_Static_Svc_Descriptor &ssd, bool force_replace=false) |
int | process_directives_i (ACE_Svc_Conf_Param *param) |
int | initialize_i (const ACE_Service_Type *sr, const ACE_TCHAR *parameters) |
const ACE_Static_Svc_Descriptor * | find_processed_static_svc (const ACE_TCHAR *) |
void | add_processed_static_svc (const ACE_Static_Svc_Descriptor *) |
Captures a list of the direcives processed (explicitely) for this Gestalt so that services can be replicated in other repositories upon their first initialization. | |
int | init_i (void) |
Protected Attributes | |
bool | svc_repo_is_owned_ |
size_t | svc_repo_size_ |
int | is_opened_ |
const ACE_TCHAR * | logger_key_ |
bool | no_static_svcs_ |
Should we avoid loading the static services? | |
ACE_SVC_QUEUE * | svc_queue_ |
Queue of services specified on the command-line. | |
ACE_SVC_QUEUE * | svc_conf_file_queue_ |
ACE_Service_Repository * | repo_ |
The service repository to hold the services. | |
ACE_STATIC_SVCS * | static_svcs_ |
Repository of statically linked services. | |
ACE_PROCESSED_STATIC_SVCS * | processed_static_svcs_ |
ACE_Atomic_Op< ACE_SYNCH_MUTEX, long > | refcnt_ |
Support for intrusive reference counting. | |
Private Member Functions | |
ACE_Service_Gestalt (const ACE_Service_Gestalt &) | |
ACE_Service_Gestalt & | operator= (const ACE_Service_Gestalt &) |
Friends | |
class | ACE_Dynamic_Service_Base |
class | ACE_Service_Object |
class | ACE_Service_Config |
class | ACE_Service_Config_Guard |
Classes | |
struct | Processed_Static_Svc |
The Gestalt embodies the concept of configuration context. On one hand, it is a flat namespace, where names correspond to a Service Object instance. A Gestalt owns the Service Repository instance, which in turn owns the Service Object instances.
Another aspect of a Gestalt is its responsibility for record-keeping and accounting for the meta-data, necessary for locating, removing or instantiating a service.
A repository underlies an instance of a gestalt and its lifetime may or may not be bounded by the lifetime of the gestalt, that owns it. This feature is important for the derived classes and the Service Config in particular.
typedef ACE_Unbounded_Queue<ACE_TString> ACE_Service_Gestalt::ACE_SVC_QUEUE [protected] |
typedef ACE_Unbounded_Queue_Iterator<ACE_TString> ACE_Service_Gestalt::ACE_SVC_QUEUE_ITERATOR [protected] |
typedef ACE_Unbounded_Set<ACE_Static_Svc_Descriptor *> ACE_Service_Gestalt::ACE_STATIC_SVCS [protected] |
typedef ACE_Unbounded_Set_Iterator<ACE_Static_Svc_Descriptor *> ACE_Service_Gestalt::ACE_STATIC_SVCS_ITERATOR [protected] |
typedef ACE_Unbounded_Set<Processed_Static_Svc *> ACE_Service_Gestalt::ACE_PROCESSED_STATIC_SVCS [protected] |
typedef ACE_Unbounded_Set_Iterator<Processed_Static_Svc *> ACE_Service_Gestalt::ACE_PROCESSED_STATIC_SVCS_ITERATOR [protected] |
ACE_Service_Gestalt::ACE_Service_Gestalt | ( | const ACE_Service_Gestalt & | ) | [private] |
Not implemented to enforce no copying
ACE_Service_Gestalt::ACE_Service_Gestalt | ( | size_t | size = 1024 , |
|
bool | svc_repo_is_owned = true , |
|||
bool | no_static_svcs = true | |||
) |
Constructor either associates the instance with the process-wide singleton instance of ACE_Service_Repository, or creates and manages its own instance of the specified size.
ACE_Service_Gestalt::~ACE_Service_Gestalt | ( | void | ) | [virtual] |
Perform user-specified close activities and remove dynamic memory.
ACE_Service_Gestalt& ACE_Service_Gestalt::operator= | ( | const ACE_Service_Gestalt & | ) | [private] |
void ACE_Service_Gestalt::dump | ( | void | ) | const |
Dump the state of an object.
ACE_BEGIN_VERSIONED_NAMESPACE_DECL ACE_INLINE int ACE_Service_Gestalt::open | ( | const ACE_TCHAR | program_name[], | |
const ACE_TCHAR * | logger_key = ACE_DEFAULT_LOGGER_KEY , |
|||
bool | ignore_static_svcs = true , |
|||
bool | ignore_default_svc_conf_file = false , |
|||
bool | ignore_debug_flag = false | |||
) |
Performs an open without parsing command-line arguments. The logger_key indicates where to write the logging output, which is typically either a STREAM pipe or a socket address. If ignore_static_svcs is true then static services are not loaded, otherwise, they are loaded. If ignore_default_svc_conf_file is true then the <svc.conf> configuration file will be ignored. Returns zero upon success, -1 if the file is not found or cannot be opened (errno is set accordingly), otherwise returns the number of errors encountered loading the services in the specified svc.conf configuration file. If ignore_debug_flag is true then the application is responsible for setting the <ACE_Log_Msg::priority_mask> appropriately.
ACE_INLINE int ACE_Service_Gestalt::open | ( | int | argc, | |
ACE_TCHAR * | argv[], | |||
const ACE_TCHAR * | logger_key = ACE_DEFAULT_LOGGER_KEY , |
|||
bool | ignore_static_svcs = true , |
|||
bool | ignore_default_svc_conf_file = false , |
|||
bool | ignore_debug_flag = false | |||
) |
This is the primary entry point into the ACE_Service_Config (the constructor just handles simple initializations). It parses arguments passed in from argc and argv parameters. The arguments that are valid in a call to this method include:
chroot()
to the appropriate directory.
argc | The number of commandline arguments. | |
argv | The array with commandline arguments | |
logger_key | Indicates where to write the logging output, which is typically either a STREAM pipe or a socket address. | |
ignore_static_svcs | If true then static services are not loaded, otherwise, they are loaded. | |
ignore_default_svc_conf_file | If false then the svc.conf configuration file will be ignored. | |
ignore_debug_flag | If false then the application is responsible for setting the ACE_Log_Msg::priority_mask appropriately. |
-1 | The configuration file is not found or cannot be opened (errno is set accordingly). | |
0 | Success. | |
>0 | The number of errors encountered while processing the service configuration file(s). |
int ACE_Service_Gestalt::is_opened | ( | void | ) |
Has it been opened? Returns the difference between the times open and close have been called on this instance
int ACE_Service_Gestalt::process_directive | ( | const ACE_TCHAR | directive[] | ) |
Process one service configuration directive, which is passed as a string. Returns the number of errors that occurred.
int ACE_Service_Gestalt::process_directive | ( | const ACE_Static_Svc_Descriptor & | ssd, | |
bool | force_replace = false | |||
) |
Process one static service definition.
Load a new static service.
ssd | Service descriptor, see the document of ACE_Static_Svc_Descriptor for more details. | |
force_replace | If set the new service descriptor replaces any previous instance in the repository. |
int ACE_Service_Gestalt::process_file | ( | const ACE_TCHAR | file[] | ) |
Process a file containing a list of service configuration directives.
ACE_INLINE int ACE_Service_Gestalt::find | ( | const ACE_TCHAR | name[], | |
const ACE_Service_Type ** | srp = 0 , |
|||
int | ignore_suspended = 1 | |||
) | const |
Searches for a service object declaration in the local repo, only.
Locate an entry with name in the table. If <ignore_suspended> is set then only consider services marked as resumed. If the caller wants the located entry, pass back a pointer to the located entry via <srp>. If name is not found, -1 is returned. If name is found, but it is suspended and the caller wants to ignore suspended services a -2 is returned.
int ACE_Service_Gestalt::parse_args | ( | int | argc, | |
ACE_TCHAR * | argv[] | |||
) |
Handle the command-line options intended for the <ACE_Service_Gestalt>. Note that <argv[0]> is assumed to be the program name.
The arguments that are valid in a call to this method are
int ACE_Service_Gestalt::process_directives | ( | bool | ignore_default_svc_conf_file | ) |
Process (or re-process) service configuration requests that are provided in the svc.conf file(s). Returns the number of errors that occurred.
int ACE_Service_Gestalt::close | ( | void | ) |
Tidy up and perform last rites when ACE_Service_Config is shut down. This method calls <close_svcs>. Returns 0.
int ACE_Service_Gestalt::insert | ( | ACE_Static_Svc_Descriptor * | stsd | ) |
Queues a static service object descriptor which, during open() will be given to process_directive() to create the Service Object. Normally, only called from static initializers, prior to calling open() but loading a service from a DLL can cause it too.
int ACE_Service_Gestalt::initialize | ( | const ACE_Service_Type_Factory * | stf, | |
const ACE_TCHAR * | parameters | |||
) |
Dynamically link the shared object file and retrieve a pointer to the designated shared object in this file. Also account for the possiblity to have static services registered when loading the DLL, by ensuring that the dynamic sevice is registered before any of its subordibnate static services. Thus avoiding any finalization order problems.
int ACE_Service_Gestalt::initialize | ( | const ACE_Service_Type * | sr, | |
const ACE_TCHAR * | parameters | |||
) |
Initialize and activate a statically svc_name service.
If initialization fails ...
int ACE_Service_Gestalt::resume | ( | const ACE_TCHAR | svc_name[] | ) |
Resume a svc_name that was previously suspended or has not yet been resumed (e.g., a static service).
int ACE_Service_Gestalt::suspend | ( | const ACE_TCHAR | svc_name[] | ) |
Suspend svc_name. Note that this will not unlink the service from the daemon if it was dynamically linked, it will mark it as being suspended in the Service Repository and call the <suspend> member function on the appropriate <ACE_Service_Object>. A service can be resumed later on by calling the <RESUME> member function...
int ACE_Service_Gestalt::remove | ( | const ACE_TCHAR | svc_name[] | ) |
Totally remove svc_name from the daemon by removing it from the ACE_Reactor, and unlinking it if necessary.
int ACE_Service_Gestalt::find_static_svc_descriptor | ( | const ACE_TCHAR * | name, | |
ACE_Static_Svc_Descriptor ** | ssd = 0 | |||
) | const |
Find a static service descriptor by name.
Using the supplied name, finds and (if needed) returns a pointer to a static service descriptor. Returns 0 for success and -1 for failure
ACE_INLINE ACE_Service_Repository * ACE_Service_Gestalt::current_service_repository | ( | void | ) |
Get the current ACE_Service_Repository held by this object.
int ACE_Service_Gestalt::parse_args_i | ( | int | argc, | |
ACE_TCHAR * | argv[], | |||
bool & | ignore_default_svc_conf_file | |||
) | [protected, virtual] |
int ACE_Service_Gestalt::open_i | ( | const ACE_TCHAR | program_name[], | |
const ACE_TCHAR * | logger_key = ACE_DEFAULT_LOGGER_KEY , |
|||
bool | ignore_static_svcs = true , |
|||
bool | ignore_default_svc_conf_file = false , |
|||
bool | ignore_debug_flag = false | |||
) | [protected, virtual] |
Performs an open without parsing command-line arguments. The logger_key indicates where to write the logging output, which is typically either a STREAM pipe or a socket address. If ignore_default_svc_conf_file is non-0 then the "svc.conf" file will be ignored. If ignore_debug_flag is non-0 then the application is responsible for setting the ACE_Log_Msg::priority_mask()
appropriately. Returns number of errors that occurred on failure and 0 otherwise.
int ACE_Service_Gestalt::init_svc_conf_file_queue | ( | void | ) | [protected] |
Initialize the <svc_conf_file_queue_> if necessary.
int ACE_Service_Gestalt::load_static_svcs | ( | void | ) | [protected] |
Add the default statically-linked services to the ACE_Service_Repository.
int ACE_Service_Gestalt::process_commandline_directives | ( | void | ) | [protected] |
Process service configuration requests that were provided on the command-line. Returns the number of errors that occurred.
int ACE_Service_Gestalt::process_directive_i | ( | const ACE_Static_Svc_Descriptor & | ssd, | |
bool | force_replace = false | |||
) | [protected] |
Process a static directive without also inserting its descriptor the global table. This avoids multiple additions when processing directives in non-global gestalts.
int ACE_Service_Gestalt::process_directives_i | ( | ACE_Svc_Conf_Param * | param | ) | [protected] |
This is the implementation function that process_directives() and process_directive() both call. Returns the number of errors that occurred.
int ACE_Service_Gestalt::initialize_i | ( | const ACE_Service_Type * | sr, | |
const ACE_TCHAR * | parameters | |||
) | [protected] |
const ACE_Static_Svc_Descriptor * ACE_Service_Gestalt::find_processed_static_svc | ( | const ACE_TCHAR * | name | ) | [protected] |
void ACE_Service_Gestalt::add_processed_static_svc | ( | const ACE_Static_Svc_Descriptor * | assd | ) | [protected] |
Captures a list of the direcives processed (explicitely) for this Gestalt so that services can be replicated in other repositories upon their first initialization.
This is part of the mechanism ensuring distinct local instances for static service objects, loaded in another repository.
When process_directive(Static_Svc_Descriptor&) is called, it associates a service object with the Gestalt and makes the resource (a Service Object) local to the repository. This is but the first step in using such SO. The next is the "initialization" step. It is typicaly done through a "static" service configuration directive.
In contrast a "dynamic" directive, when processed through the overloaded process_directives(string) both creates the SO locally and initializes it, where the statics directive must first locate the SO and then calls the init() method. This means that durig the "static" initialization there's no specific information about the hosting repository and the gestalt must employ some lookup strategy to find it elsewhere.
int ACE_Service_Gestalt::init_i | ( | void | ) | [protected] |
Performs the common initialization tasks for a new or previously closed instance. Must not be virtual, as it is called from the constructor.
Performs the common initialization tasks for a new or previously closed instance. Must not be virtual, as it is also called from the constructor.
void ACE_Service_Gestalt::intrusive_add_ref | ( | ACE_Service_Gestalt * | g | ) | [static] |
void ACE_Service_Gestalt::intrusive_remove_ref | ( | ACE_Service_Gestalt * | g | ) | [static] |
friend class ACE_Dynamic_Service_Base [friend] |
friend class ACE_Service_Object [friend] |
friend class ACE_Service_Config [friend] |
friend class ACE_Service_Config_Guard [friend] |
Declare the dynamic allocation hooks.
bool ACE_Service_Gestalt::svc_repo_is_owned_ [protected] |
Do we own the service repository instance, or have only been given a ptr to the singleton?
size_t ACE_Service_Gestalt::svc_repo_size_ [protected] |
Repository size is necessary, so that we can close (which may destroy the repository instance), and then re-open again.
int ACE_Service_Gestalt::is_opened_ [protected] |
Keep track of the number of times the instance has been initialized (opened). "If so, we can't allow <yyparse> to be called since it's not reentrant" is the original motivation, but that does not seem to be the case anymore. This variable is incremented by the <ACE_Service_Gestalt::open> method and decremented by the <ACE_Service_Gestalt::close> method.
const ACE_TCHAR* ACE_Service_Gestalt::logger_key_ [protected] |
Indicates where to write the logging output. This is typically either a STREAM pipe or a socket
bool ACE_Service_Gestalt::no_static_svcs_ [protected] |
Should we avoid loading the static services?
ACE_SVC_QUEUE* ACE_Service_Gestalt::svc_queue_ [protected] |
Queue of services specified on the command-line.
ACE_SVC_QUEUE* ACE_Service_Gestalt::svc_conf_file_queue_ [protected] |
Queue of svc.conf files specified on the command-line. @ This should probably be made to handle unicode filenames...
ACE_Service_Repository* ACE_Service_Gestalt::repo_ [protected] |
The service repository to hold the services.
ACE_STATIC_SVCS* ACE_Service_Gestalt::static_svcs_ [protected] |
Repository of statically linked services.
Repository of statically linked services for which process directive was called, but the service is not already a member of the static_svcs_ list.
ACE_Atomic_Op<ACE_SYNCH_MUTEX, long> ACE_Service_Gestalt::refcnt_ [protected] |
Support for intrusive reference counting.
