Public Types |
| enum | { M_DELETE = 3
} |
Public Methods |
| | ACE_Stream (void *arg=0, ACE_Module< ACE_SYNCH_USE > *head=0, ACE_Module< ACE_SYNCH_USE > *tail=0) |
| virtual int | open (void *arg, ACE_Module< ACE_SYNCH_USE > *head=0, ACE_Module< ACE_SYNCH_USE > *tail=0) |
| virtual int | close (int flags=M_DELETE) |
| | Close down the stream and release all the resources.
|
| virtual | ~ACE_Stream (void) |
| | Close down the stream and release all the resources.
|
| virtual int | push (ACE_Module< ACE_SYNCH_USE > *mod) |
| | Add a new module <mod> right below the Stream head.
|
| virtual int | pop (int flags=M_DELETE) |
| | Remove the <mod> right below the Stream head and close it down.
|
| virtual int | top (ACE_Module< ACE_SYNCH_USE > *&mod) |
| virtual int | insert (const ACE_TCHAR *prev_name, ACE_Module< ACE_SYNCH_USE > *mod) |
| | Insert a new module <mod> below the named module <prev_name>.
|
| virtual int | replace (const ACE_TCHAR *replace_name, ACE_Module< ACE_SYNCH_USE > *mod, int flags=M_DELETE) |
| | Replace the named module <replace_name> with a new module <mod>.
|
| virtual int | remove (const ACE_TCHAR *mod, int flags=M_DELETE) |
| virtual ACE_Module< ACE_SYNCH_USE > * | head (void) |
| | Return current stream head.
|
| virtual ACE_Module< ACE_SYNCH_USE > * | tail (void) |
| | Return current stream tail.
|
| virtual ACE_Module< ACE_SYNCH_USE > * | find (const ACE_TCHAR *mod) |
| | Find a particular ACE_Module.
|
| virtual int | link (ACE_Stream< ACE_SYNCH_USE > &) |
| | Create a pipe between two Streams.
|
| virtual int | unlink (void) |
| | Remove a pipe formed between two Streams.
|
| virtual int | put (ACE_Message_Block *mb, ACE_Time_Value *timeout=0) |
| virtual int | get (ACE_Message_Block *&mb, ACE_Time_Value *timeout=0) |
| virtual int | control (ACE_IO_Cntl_Msg::ACE_IO_Cntl_Cmds cmd, void *args) |
| | Send control message down the stream.
|
| virtual int | wait (void) |
| | Synchronize with the final close of the stream.
|
| virtual void | dump (void) const |
| | Dump the state of an object.
|
Public Attributes |
| | ACE_ALLOC_HOOK_DECLARE |
| | Declare the dynamic allocation hooks.
|
Private Methods |
| int | unlink_i (void) |
| int | link_i (ACE_Stream< ACE_SYNCH_USE > &) |
| int | push_module (ACE_Module< ACE_SYNCH_USE > *, ACE_Module< ACE_SYNCH_USE > *=0, ACE_Module< ACE_SYNCH_USE > *=0) |
| | Must a new module onto the Stream.
|
Private Attributes |
| ACE_Module< ACE_SYNCH_USE > * | stream_head_ |
| | Pointer to the head of the stream.
|
| ACE_Module< ACE_SYNCH_USE > * | stream_tail_ |
| | Pointer to the tail of the stream.
|
| ACE_Stream< ACE_SYNCH_USE > * | linked_us_ |
| | Pointer to an adjoining linked stream.
|
| ACE_SYNCH_MUTEX_T | lock_ |
| | Protect the stream against race conditions.
|
| ACE_SYNCH_CONDITION_T | final_close_ |
| | Use to tell all threads waiting on the close that we are done.
|
Friends |
| class | ACE_Stream_Iterator< ACE_SYNCH_USE > |
A Stream consists of a stack of <ACE_Modules>, each of which contains two <ACE_Tasks>. Even though the methods in this class are virtual, this class isn't really intended for subclassing unless you know what you are doing. In particular, the <ACE_Stream> destructor calls <close>, which won't be overridden properly unless you call it in a subclass destructor.
