ACE
6.0.6

Provides a very fast and predictable timer implementation. More...
#include <Timer_Heap_T.h>
Public Types
typedef ACE_Timer_Heap_Iterator_T < TYPE, FUNCTOR, ACE_LOCK >  HEAP_ITERATOR
typedef ACE_Timer_Queue_T < TYPE, FUNCTOR, ACE_LOCK >  INHERITED
Public Member Functions
ACE_Timer_Heap_T (size_t size, bool preallocated=false, FUNCTOR *upcall_functor=0, ACE_Free_List< ACE_Timer_Node_T< TYPE > > *freelist=0)
ACE_Timer_Heap_T (FUNCTOR *upcall_functor=0, ACE_Free_List< ACE_Timer_Node_T< TYPE > > *freelist=0)
virtual  ~ACE_Timer_Heap_T (void)
Destructor.
virtual bool  is_empty (void) const
True if heap is empty, else false.
virtual const ACE_Time_Value &  earliest_time (void) const
virtual int  reset_interval (long timer_id, const ACE_Time_Value &interval)
virtual int  cancel (const TYPE &type, int dont_call_handle_close=1)
virtual int  cancel (long timer_id, const void **act=0, int dont_call_handle_close=1)
virtual ACE_Timer_Queue_Iterator_T < TYPE, FUNCTOR, ACE_LOCK > &  iter (void)
Returns a pointer to this ACE_Timer_Queue's iterator.
ACE_Timer_Node_T< TYPE > *  remove_first (void)
virtual void  dump (void) const
Dump the state of an object.
virtual ACE_Timer_Node_T< TYPE > *  get_first (void)
Reads the earliest node from the queue and returns it.
Protected Member Functions
virtual long  schedule_i (const TYPE &type, const void *act, const ACE_Time_Value &future_time, const ACE_Time_Value &interval)
virtual void  reschedule (ACE_Timer_Node_T< TYPE > *)
Reschedule an "interval" ACE_Timer_Node.
virtual ACE_Timer_Node_T< TYPE > *  alloc_node (void)
virtual void  free_node (ACE_Timer_Node_T< TYPE > *)
Private Member Functions
ACE_Timer_Node_T< TYPE > *  remove (size_t slot)
void  insert (ACE_Timer_Node_T< TYPE > *new_node)
Insert new_node into the heap and restore the heap property.
void  grow_heap (void)
void  reheap_up (ACE_Timer_Node_T< TYPE > *new_node, size_t slot, size_t parent)
Restore the heap property, starting at slot.
void  reheap_down (ACE_Timer_Node_T< TYPE > *moved_node, size_t slot, size_t child)
Restore the heap property, starting at slot.
void  copy (size_t slot, ACE_Timer_Node_T< TYPE > *moved_node)
long  timer_id (void)
long  pop_freelist (void)
Pops and returns a new timer id from the freelist.
void  push_freelist (long old_id)
Pushes old_id onto the freelist.
ACE_Timer_Heap_T (const ACE_Timer_Heap_T< TYPE, FUNCTOR, ACE_LOCK > &)
void  operator= (const ACE_Timer_Heap_T< TYPE, FUNCTOR, ACE_LOCK > &)
Private Attributes
size_t  max_size_
Maximum size of the heap.
size_t  cur_size_
Current size of the heap.
size_t  cur_limbo_
HEAP_ITERATOR *  iterator_
Iterator used to expire timers.
ACE_Timer_Node_T< TYPE > **  heap_
ssize_t *  timer_ids_
size_t  timer_ids_curr_
size_t  timer_ids_min_free_
ACE_Timer_Node_T< TYPE > *  preallocated_nodes_
ACE_Timer_Node_T< TYPE > *  preallocated_nodes_freelist_
ACE_Unbounded_Set < ACE_Timer_Node_T< TYPE > * >  preallocated_node_set_
Friends
class  ACE_Timer_Heap_Iterator_T< TYPE, FUNCTOR, ACE_LOCK >
Provides a very fast and predictable timer implementation.
This implementation uses a heapbased callout queue of absolute times. Therefore, in the average and worst case, scheduling, canceling, and expiring timers is O(log N) (where N is the total number of timers). In addition, we can also preallocate as many ACE_Timer_Node
objects as there are slots in the heap. This allows us to completely remove the need for dynamic memory allocation, which is important for realtime systems.
typedef ACE_Timer_Heap_Iterator_T<TYPE, FUNCTOR, ACE_LOCK> ACE_Timer_Heap_T::HEAP_ITERATOR
typedef ACE_Timer_Queue_T<TYPE, FUNCTOR, ACE_LOCK> ACE_Timer_Heap_T::INHERITED
ACE_Timer_Heap_T::ACE_Timer_Heap_T  (  size_t  size,
bool  preallocated = false ,

FUNCTOR *  upcall_functor = 0 ,

ACE_Free_List< ACE_Timer_Node_T< TYPE > > *  freelist = 0

)
The Constructor creates a heap with specified number of elements. This can also take in a upcall functor and freelist (if 0, then defaults will be created).
size  The maximum number of timers that can be inserted into the new object.
preallocated  Default false, true then all the memory for the ACE_Timer_Node objects will be preallocated. This saves time and is more predictable (though it requires more space). Otherwise, timer nodes are allocated as needed.
freelist  is the freelist of timer nodes.
upcall_functor  If 0 Timer Heap will create a default FUNCTOR.
ACE_Timer_Heap_T::ACE_Timer_Heap_T  (  FUNCTOR *  upcall_functor = 0 ,
ACE_Free_List< ACE_Timer_Node_T< TYPE > > *  freelist = 0

)
Default constructor. upcall_functor
is the instance of the FUNCTOR to be used by the queue. If upcall_functor
is 0, Timer Heap will create a default FUNCTOR. freelist
is the freelist of timer nodes. If 0, then a default freelist will be created. The default size will be ACE_DEFAULT_TIMERS and there will be no preallocation.
virtual ACE_Timer_Heap_T::~ACE_Timer_Heap_T  (  void  )  [virtual]
Destructor.
ACE_Timer_Heap_T::ACE_Timer_Heap_T  (  const ACE_Timer_Heap_T< TYPE, FUNCTOR, ACE_LOCK > &  )  [private]
virtual ACE_Timer_Node_T<TYPE>* ACE_Timer_Heap_T::alloc_node  (  void  )  [protected, virtual]
Factory method that allocates a new node (uses operator new if we're *not* preallocating, otherwise uses an internal freelist).
Reimplemented from ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual int ACE_Timer_Heap_T::cancel  (  const TYPE &  type,
int  dont_call_handle_close = 1

)  [virtual]
Cancel all timers associated with type. If dont_call_handle_close is 0 then the <functor> will be invoked. Returns number of timers cancelled.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual int ACE_Timer_Heap_T::cancel  (  long  timer_id,
const void **  act = 0 ,

int  dont_call_handle_close = 1

)  [virtual]
Cancel the single timer that matches the timer_id value (which was returned from the <schedule> method). If act is nonNULL then it will be set to point to the ``magic cookie'' argument passed in when the timer was registered. This makes it possible to free up the memory and avoid memory leaks. If dont_call_handle_close is 0 then the <functor> will be invoked. Returns 1 if cancellation succeeded and 0 if the timer_id wasn't found.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
void ACE_Timer_Heap_T::copy  (  size_t  slot,
ACE_Timer_Node_T< TYPE > *  moved_node
)  [private]
Copy moved_node into the slot slot of <heap_> and move slot into the corresponding slot in the <timer_id_> array.
virtual void ACE_Timer_Heap_T::dump  (  void  )  const [virtual]
Dump the state of an object.
Reimplemented from ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual const ACE_Time_Value& ACE_Timer_Heap_T::earliest_time  (  void  )  const [virtual]
Returns the time of the earliest node in the Timer_Queue. Must be called on a nonempty queue.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual void ACE_Timer_Heap_T::free_node  (  ACE_Timer_Node_T< TYPE > *  )  [protected, virtual]
Factory method that frees a previously allocated node (uses operator delete if we're *not* preallocating, otherwise uses an internal freelist).
Reimplemented from ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual ACE_Timer_Node_T<TYPE>* ACE_Timer_Heap_T::get_first  (  void  )  [virtual]
Reads the earliest node from the queue and returns it.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
void ACE_Timer_Heap_T::grow_heap  (  void  )  [private]
Doubles the size of the heap and the corresponding timer_ids array. If preallocation is used, will also double the size of the preallocated array of ACE_Timer_Nodes.
void ACE_Timer_Heap_T::insert  (  ACE_Timer_Node_T< TYPE > *  new_node  )  [private]
Insert new_node into the heap and restore the heap property.
virtual bool ACE_Timer_Heap_T::is_empty  (  void  )  const [virtual]
True if heap is empty, else false.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual ACE_Timer_Queue_Iterator_T<TYPE, FUNCTOR, ACE_LOCK>& ACE_Timer_Heap_T::iter  (  void  )  [virtual]
Returns a pointer to this ACE_Timer_Queue's iterator.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
void ACE_Timer_Heap_T::operator=  (  const ACE_Timer_Heap_T< TYPE, FUNCTOR, ACE_LOCK > &  )  [private]
long ACE_Timer_Heap_T::pop_freelist  (  void  )  [private]
Pops and returns a new timer id from the freelist.
void ACE_Timer_Heap_T::push_freelist  (  long  old_id  )  [private]
Pushes old_id onto the freelist.
void ACE_Timer_Heap_T::reheap_down  (  ACE_Timer_Node_T< TYPE > *  moved_node,
size_t  slot,
size_t  child
)  [private]
Restore the heap property, starting at slot.
void ACE_Timer_Heap_T::reheap_up  (  ACE_Timer_Node_T< TYPE > *  new_node,
size_t  slot,
size_t  parent
)  [private]
Restore the heap property, starting at slot.
ACE_Timer_Node_T<TYPE>* ACE_Timer_Heap_T::remove  (  size_t  slot  )  [private]
Remove and return the sloth ACE_Timer_Node and restore the heap property.
ACE_Timer_Node_T<TYPE>* ACE_Timer_Heap_T::remove_first  (  void  )  [virtual]
Removes the earliest node from the queue and returns it. Note that the timer is removed from the heap, but is not freed, and its ID is not reclaimed. The caller is responsible for calling either reschedule()
or free_node()
after this function returns. Thus, this function is for support of ACE_Timer_Queue::expire
and should not be used unadvisedly in other conditions.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual void ACE_Timer_Heap_T::reschedule  (  ACE_Timer_Node_T< TYPE > *  )  [protected, virtual]
Reschedule an "interval" ACE_Timer_Node.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual int ACE_Timer_Heap_T::reset_interval  (  long  timer_id,
const ACE_Time_Value &  interval
)  [virtual]
Resets the interval of the timer represented by timer_id to interval, which is specified in relative time to the current <gettimeofday>. If interval is equal to ACE_Time_Value::zero, the timer will become a nonrescheduling timer. Returns 0 if successful, 1 if not.
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
virtual long ACE_Timer_Heap_T::schedule_i  (  const TYPE &  type,
const void *  act,
const ACE_Time_Value &  future_time,
const ACE_Time_Value &  interval
)  [protected, virtual]
Schedule a timer that may optionally autoreset. Schedule type that will expire at future_time, which is specified in absolute time. If it expires then act is passed in as the value to the <functor>. If interval is != to ACE_Time_Value::zero then it is used to reschedule the type automatically, using relative time to the current <gettimeofday>. This method returns a <timer_id> that uniquely identifies the the type entry in an internal list. This <timer_id> can be used to cancel the timer before it expires. The cancellation ensures that <timer_ids> are unique up to values of greater than 2 billion timers. As long as timers don't stay around longer than this there should be no problems with accidentally deleting the wrong timer. Returns 1 on failure (which is guaranteed never to be a valid <timer_id>).
Implements ACE_Timer_Queue_T< TYPE, FUNCTOR, ACE_LOCK >.
long ACE_Timer_Heap_T::timer_id  (  void  )  [private]
Returns a timer id that uniquely identifies this timer. This id can be used to cancel a timer via the <cancel (int)> method. The timer id returned from this method will never == 1 to avoid conflicts with other failure return values.
friend class ACE_Timer_Heap_Iterator_T< TYPE, FUNCTOR, ACE_LOCK > [friend]
size_t ACE_Timer_Heap_T::cur_limbo_ [private]
Number of heap entries in transition (removed from the queue, but not freed) and may be rescheduled or freed.
size_t ACE_Timer_Heap_T::cur_size_ [private]
Current size of the heap.
ACE_Timer_Node_T<TYPE>** ACE_Timer_Heap_T::heap_ [private]
Current contents of the Heap, which is organized as a "heap" of ACE_Timer_Node *'s. In this context, a heap is a "partially ordered, almost complete" binary tree, which is stored in an array.
HEAP_ITERATOR* ACE_Timer_Heap_T::iterator_ [private]
Iterator used to expire timers.
size_t ACE_Timer_Heap_T::max_size_ [private]
Maximum size of the heap.
ACE_Unbounded_Set<ACE_Timer_Node_T<TYPE> *> ACE_Timer_Heap_T::preallocated_node_set_ [private]
Set of pointers to the arrays of preallocated timer nodes. Used to delete the allocated memory when required.
ACE_Timer_Node_T<TYPE>* ACE_Timer_Heap_T::preallocated_nodes_ [private]
If this is non0, then we preallocate <max_size_> number of ACE_Timer_Node objects in order to reduce dynamic allocation costs. In autogrowing implementation, this points to the last array of nodes allocated.
ACE_Timer_Node_T<TYPE>* ACE_Timer_Heap_T::preallocated_nodes_freelist_ [private]
This points to the head of the <preallocated_nodes_> freelist, which is organized as a stack.
ssize_t* ACE_Timer_Heap_T::timer_ids_ [private]
An array of "pointers" that allows each ACE_Timer_Node in the <heap_> to be located in O(1) time. Basically, <timer_id_[i]> contains the slot in the <heap_> array where an ACE_Timer_Node * with timer id <i> resides. Thus, the timer id passed back from <schedule> is really a slot into the <timer_ids> array. The <timer_ids_> array serves two purposes: negative values are indications of free timer IDs, whereas positive values are "pointers" into the <heap_> array for assigned timer IDs.
size_t ACE_Timer_Heap_T::timer_ids_curr_ [private]
"Pointer" to the element in the <timer_ids_> array that was last given out as a timer ID.
size_t ACE_Timer_Heap_T::timer_ids_min_free_ [private]
Index representing the lowest timer ID that has been freed. When the timer_ids_next_ value wraps around, it starts back at this point.
