#include <Transport_Cache_Manager.h>
Public Types | |
typedef ACE_Hash_Map_Manager_Ex < Cache_ExtId, Cache_IntId, ACE_Hash< Cache_ExtId >, ACE_Equal_To< Cache_ExtId >, ACE_Null_Mutex > | HASH_MAP |
typedef HASH_MAP::iterator | HASH_MAP_ITER |
typedef ACE_Hash_Map_Entry < Cache_ExtId, Cache_IntId > | HASH_MAP_ENTRY |
typedef TAO_Condition < TAO_SYNCH_MUTEX > | CONDITION |
Public Member Functions | |
Transport_Cache_Manager (TAO_ORB_Core &orb_core) | |
Constructor. | |
~Transport_Cache_Manager (void) | |
Destructor. | |
int | cache_transport (TAO_Transport_Descriptor_Interface *prop, TAO_Transport *transport) |
Add the transport to the cache. | |
int | cache_idle_transport (TAO_Transport_Descriptor_Interface *prop, TAO_Transport *transport) |
int | find_transport (TAO_Transport_Descriptor_Interface *prop, TAO_Transport *&transport) |
int | purge (void) |
Remove entries from the cache depending upon the strategy. | |
int | purge_entry (HASH_MAP_ENTRY *&) |
Purge the entry from the Cache Map. | |
void | mark_invalid (HASH_MAP_ENTRY *&) |
Mark the entry as invalid for use but keep it in cache. | |
int | make_idle (HASH_MAP_ENTRY *&entry) |
Make the entry idle and ready for use. | |
int | update_entry (HASH_MAP_ENTRY *&entry) |
int | close (Connection_Handler_Set &handlers) |
bool | blockable_client_transports (Connection_Handler_Set &handlers) |
size_t | current_size (void) const |
Return the current size of the cache. | |
size_t | total_size (void) const |
Return the total size of the cache. | |
HASH_MAP & | map (void) |
Return the underlying cache map. | |
Private Types | |
typedef HASH_MAP_ENTRY ** | DESCRIPTOR_SET |
Private Member Functions | |
int | bind (Cache_ExtId &ext_id, Cache_IntId &int_id) |
int | find (const Cache_ExtId &key, Cache_IntId &value) |
int | bind_i (Cache_ExtId &ext_id, Cache_IntId &int_id) |
int | find_i (const Cache_ExtId &key, Cache_IntId &value) |
int | make_idle_i (HASH_MAP_ENTRY *&entry) |
Non-locking version and actual implementation of make_idle (). | |
int | close_i (Connection_Handler_Set &handlers) |
Non-locking version and actual implementation of close (). | |
int | purge_entry_i (HASH_MAP_ENTRY *&entry) |
Purge the entry from the Cache Map. | |
void | mark_invalid_i (HASH_MAP_ENTRY *&) |
Mark the entry as invalid for use but keep it in cache. | |
int | get_last_index_bind (Cache_ExtId &key, Cache_IntId &val, HASH_MAP_ENTRY *&entry) |
bool | is_entry_idle (HASH_MAP_ENTRY *&entry) |
void | sort_set (DESCRIPTOR_SET &entries, int size) |
Sort the list of entries. | |
int | fill_set_i (DESCRIPTOR_SET &sorted_set) |
int | wait_for_connection (Cache_ExtId &extid) |
int | is_wakeup_useful (Cache_ExtId &extid) |
Is the wakeup useful todo some work? | |
bool | blockable_client_transports_i (Connection_Handler_Set &handlers) |
Non-locking version of blockable_client_transports (). | |
Static Private Member Functions | |
static int | cpscmp (const void *a, const void *b) |
Used by qsort. | |
Private Attributes | |
int | percent_ |
The percentage of the cache to purge at one time. | |
TAO_Connection_Purging_Strategy * | purging_strategy_ |
The underlying connection purging strategy. | |
HASH_MAP | cache_map_ |
The hash map that has the connections. | |
CONDITION * | condition_ |
The condition variable. | |
ACE_Lock * | cache_lock_ |
The lock that is used by the cache map. | |
CORBA::ULong | muxed_number_ |
Number of allowed muxed connections. | |
int | no_waiting_threads_ |
Number of threads waiting for connections. | |
Cache_ExtId * | last_entry_returned_ |
This class provides interfaces associating a TAO_Cache_ExtId & TAO_Cache_IntId. This class is wrapper around the ACE_Hash_Map_Manager class which is used as a container to Cache the connections. This class protects the entries with a lock. The map is updated only by holding the lock. The more compelling reason to have the lock in this class and not in the Hash_Map is that, we do quite a bit of work in this class for which we need a lock.
typedef ACE_Hash_Map_Manager_Ex<Cache_ExtId, Cache_IntId, ACE_Hash<Cache_ExtId>, ACE_Equal_To<Cache_ExtId>, ACE_Null_Mutex> TAO::Transport_Cache_Manager::HASH_MAP |
typedef HASH_MAP::iterator TAO::Transport_Cache_Manager::HASH_MAP_ITER |
typedef ACE_Hash_Map_Entry<Cache_ExtId, Cache_IntId> TAO::Transport_Cache_Manager::HASH_MAP_ENTRY |
typedef TAO_Condition<TAO_SYNCH_MUTEX> TAO::Transport_Cache_Manager::CONDITION |
typedef HASH_MAP_ENTRY** TAO::Transport_Cache_Manager::DESCRIPTOR_SET [private] |
TAO::Transport_Cache_Manager::Transport_Cache_Manager | ( | TAO_ORB_Core & | orb_core | ) |
Constructor.
If the cache is not going to be locked then dont create a condition variable. Make the <muxed_number_> to 0, else a single thread could get into waiting mode
TAO::Transport_Cache_Manager::~Transport_Cache_Manager | ( | void | ) |
Destructor.
ACE_INLINE int TAO::Transport_Cache_Manager::cache_transport | ( | TAO_Transport_Descriptor_Interface * | prop, | |
TAO_Transport * | transport | |||
) |
Add the transport to the cache.
The transport has the property definition based on which caching can be done. This method marks the transport ACE_RECYCLABLE_BUSY
which helps the threads opening up connections to use the transport immediately.
ACE_INLINE int TAO::Transport_Cache_Manager::cache_idle_transport | ( | TAO_Transport_Descriptor_Interface * | prop, | |
TAO_Transport * | transport | |||
) |
Similar to the one above, but the transport is left in ENTRY_IDLE_AND_PURGABLE
state.
int TAO::Transport_Cache_Manager::find_transport | ( | TAO_Transport_Descriptor_Interface * | prop, | |
TAO_Transport *& | transport | |||
) |
Check the Transport Cache to check whether the connection exists in the Cache and return the connection
int TAO::Transport_Cache_Manager::purge | ( | void | ) |
Remove entries from the cache depending upon the strategy.
ACE_INLINE int TAO::Transport_Cache_Manager::purge_entry | ( | HASH_MAP_ENTRY *& | entry | ) |
Purge the entry from the Cache Map.
ACE_INLINE void TAO::Transport_Cache_Manager::mark_invalid | ( | HASH_MAP_ENTRY *& | entry | ) |
Mark the entry as invalid for use but keep it in cache.
ACE_INLINE int TAO::Transport_Cache_Manager::make_idle | ( | HASH_MAP_ENTRY *& | entry | ) |
Make the entry idle and ready for use.
int TAO::Transport_Cache_Manager::update_entry | ( | HASH_MAP_ENTRY *& | entry | ) |
Mark the entry as touched. This call updates the purging strategy policy information.
ACE_INLINE int TAO::Transport_Cache_Manager::close | ( | Connection_Handler_Set & | handlers | ) |
Close the underlying hash map manager and return any handlers still registered
ACE_INLINE bool TAO::Transport_Cache_Manager::blockable_client_transports | ( | Connection_Handler_Set & | handlers | ) |
Return a set of connection handlers that belong to transports that have a RW wait strategy. This call is used for a specific use case by the ORB_Core during shutdown. The only way the ORB can wake up threads waiting on these sockstes for replies is to iterate over these blockable transports and close the socket handles. Without these the threads will continue to wait there for ever.
ACE_INLINE size_t TAO::Transport_Cache_Manager::current_size | ( | void | ) | const |
Return the current size of the cache.
ACE_INLINE size_t TAO::Transport_Cache_Manager::total_size | ( | void | ) | const |
Return the total size of the cache.
ACE_INLINE Transport_Cache_Manager::HASH_MAP & TAO::Transport_Cache_Manager::map | ( | void | ) |
Return the underlying cache map.
ACE_INLINE int TAO::Transport_Cache_Manager::bind | ( | Cache_ExtId & | ext_id, | |
Cache_IntId & | int_id | |||
) | [private] |
Associate ext_id with int_id. Grabs the lock and calls the implementation function bind_i.
int TAO::Transport_Cache_Manager::find | ( | const Cache_ExtId & | key, | |
Cache_IntId & | value | |||
) | [private] |
Lookup entry<key,value> in the cache. Grabs the lock and calls the implementation function find_i.
int TAO::Transport_Cache_Manager::bind_i | ( | Cache_ExtId & | ext_id, | |
Cache_IntId & | int_id | |||
) | [private] |
Non-Locking version and actual implementation of bind () call. Calls bind on the Hash_Map_Manager that it holds. If the bind succeeds, it adds the Hash_Map_Entry in to the Transport for its reference. If the bind fails because of an exiting entry, this method calls the get_last_index_bind ().
int TAO::Transport_Cache_Manager::find_i | ( | const Cache_ExtId & | key, | |
Cache_IntId & | value | |||
) | [private] |
Non-locking version and actual implementation of find () call. This calls the find () on the underlying Hash_Map_Manager. If the find succeeds, it calls the get_idle_transport ().
int TAO::Transport_Cache_Manager::make_idle_i | ( | HASH_MAP_ENTRY *& | entry | ) | [private] |
Non-locking version and actual implementation of make_idle ().
int TAO::Transport_Cache_Manager::close_i | ( | Connection_Handler_Set & | handlers | ) | [private] |
Non-locking version and actual implementation of close ().
int TAO::Transport_Cache_Manager::purge_entry_i | ( | HASH_MAP_ENTRY *& | entry | ) | [private] |
Purge the entry from the Cache Map.
void TAO::Transport_Cache_Manager::mark_invalid_i | ( | HASH_MAP_ENTRY *& | entry | ) | [private] |
Mark the entry as invalid for use but keep it in cache.
int TAO::Transport_Cache_Manager::get_last_index_bind | ( | Cache_ExtId & | key, | |
Cache_IntId & | val, | |||
HASH_MAP_ENTRY *& | entry | |||
) | [private] |
This is called by the bind () call when a bind fails with a available entry. When a new connection is created in TAO with an already existing endpoint, in addition to an exisitng one, we mark the connections with an index. This method, finds out the last highest index and binds the entry with an index = (last highest index + 1).
bool TAO::Transport_Cache_Manager::is_entry_idle | ( | HASH_MAP_ENTRY *& | entry | ) | [private] |
Tries to find if the <int_id_> in entry is idle for use. If it is idle it is immediately markes as busy and returns a value of 1, else it returns a value of 0
int TAO::Transport_Cache_Manager::cpscmp | ( | const void * | a, | |
const void * | b | |||
) | [static, private] |
Used by qsort.
void TAO::Transport_Cache_Manager::sort_set | ( | DESCRIPTOR_SET & | entries, | |
int | size | |||
) | [private] |
Sort the list of entries.
int TAO::Transport_Cache_Manager::fill_set_i | ( | DESCRIPTOR_SET & | sorted_set | ) | [private] |
Fill sorted_set in with the TAO_Transport_Descriptor_Interface's in a sorted order.
int TAO::Transport_Cache_Manager::wait_for_connection | ( | Cache_ExtId & | extid | ) | [private] |
Wait for connections if we have reached the limit on the number of muxed connections. If not (ie. if we dont use a muxed connection or if we have not reached the limit) this just behaves as a no-op. <extid> has all the information about the connection that is being searched.
int TAO::Transport_Cache_Manager::is_wakeup_useful | ( | Cache_ExtId & | extid | ) | [private] |
Is the wakeup useful todo some work?
bool TAO::Transport_Cache_Manager::blockable_client_transports_i | ( | Connection_Handler_Set & | handlers | ) | [private] |
Non-locking version of blockable_client_transports ().
int TAO::Transport_Cache_Manager::percent_ [private] |
The percentage of the cache to purge at one time.
TAO_Connection_Purging_Strategy* TAO::Transport_Cache_Manager::purging_strategy_ [private] |
The underlying connection purging strategy.
HASH_MAP TAO::Transport_Cache_Manager::cache_map_ [private] |
The hash map that has the connections.
CONDITION* TAO::Transport_Cache_Manager::condition_ [private] |
The condition variable.
ACE_Lock* TAO::Transport_Cache_Manager::cache_lock_ [private] |
The lock that is used by the cache map.
CORBA::ULong TAO::Transport_Cache_Manager::muxed_number_ [private] |
Number of allowed muxed connections.
int TAO::Transport_Cache_Manager::no_waiting_threads_ [private] |
Number of threads waiting for connections.
Cache_ExtId* TAO::Transport_Cache_Manager::last_entry_returned_ [private] |
This is for optimization purposes. In a situation where number of threads are waiting for connections, the last connection that is put back is cached here. This should prevent all th threads trying to search for their required entry.
