ACE_GQoS_Session Class Reference
A GQoS session object. More...
#include <QoS_Session_Impl.h>
Public Member Functions | |
| ~ACE_GQoS_Session (void) | |
| Default destructor. | |
| virtual int | open (ACE_INET_Addr dest_addr, ACE_Protocol_ID protocol_id) |
| Open a GQoS session [dest IP, dest port, Protocol ID]. | |
| virtual int | close (void) |
| Close the GQoS Session. | |
| virtual ACE_QoS | qos (void) const |
| Returns the QoS for this GQoS session. | |
| virtual int | qos (ACE_SOCK *socket, ACE_QoS_Manager *qos_manager, const ACE_QoS &ace_qos) |
| virtual void | qos (const ACE_QoS &ace_qos) |
| virtual int | update_qos (void) |
| virtual ACE_End_Point_Type | flags (void) const |
| Get/Set methods for the flags_. | |
| virtual void | flags (const ACE_End_Point_Type flags) |
| virtual ACE_INET_Addr | dest_addr (void) const |
| Get the destination address for this GQoS session. | |
| virtual void | dest_addr (const ACE_INET_Addr &dest_addr) |
| Set the destination address for this GQoS session. | |
| virtual u_short | source_port (void) const |
| Get the source port for this session. | |
| virtual void | source_port (const u_short &source_port) |
| Set the source port for this session. | |
| virtual ACE_INET_Addr * | source_addr (void) const |
| virtual void | source_addr (ACE_INET_Addr *source_addr) |
| Set the source port for this session. | |
| virtual int | session_id (void) const |
| Get the GQoS session id. | |
| virtual void | session_id (const int session_id) |
| Set the GQoS session id. | |
| virtual ACE_HANDLE | rsvp_events_handle (void) |
| Get the file descriptor of the underlying socket. | |
| virtual void | rsvp_event_type (RSVP_Event_Type event_type) |
| virtual RSVP_Event_Type | rsvp_event_type (void) |
| Set the RAPI event that last occured. | |
| virtual int | version () |
| Get the RAPI event that last occured. | |
Static Public Attributes | |
| static int | GQoS_session_id = 0 |
Private Member Functions | |
| ACE_GQoS_Session (void) | |
Friends | |
| class | ACE_QoS_Session_Factory |
Detailed Description
A GQoS session object.This class is a GQoS (Generic QoS, an implementation of RSVP on Win2K) implementation of the ACE_QoS_Session interface.
Constructor & Destructor Documentation
| ACE_BEGIN_VERSIONED_NAMESPACE_DECL ACE_INLINE ACE_GQoS_Session::~ACE_GQoS_Session | ( | void | ) |
Default destructor.
| ACE_GQoS_Session::ACE_GQoS_Session | ( | void | ) | [private] |
Default constructor. Constructor is defined private so that only the friend factory can instantiate this class.
Member Function Documentation
| int ACE_GQoS_Session::open | ( | ACE_INET_Addr | dest_addr, | |
| ACE_Protocol_ID | protocol_id | |||
| ) | [virtual] |
| int ACE_GQoS_Session::close | ( | void | ) | [virtual] |
| ACE_INLINE ACE_QoS ACE_GQoS_Session::qos | ( | void | ) | const [virtual] |
| int ACE_GQoS_Session::qos | ( | ACE_SOCK * | socket, | |
| ACE_QoS_Manager * | qos_manager, | |||
| const ACE_QoS & | ace_qos | |||
| ) | [virtual] |
Set QoS for this GQoS session. The socket parameter is used to confirm if this QoS session was subscribed to by the socket.
Implements ACE_QoS_Session.
| ACE_INLINE void ACE_GQoS_Session::qos | ( | const ACE_QoS & | ace_qos | ) | [virtual] |
Sets the QoS for this session object to ace_qos. Does not interfere with the QoS in the underlying socket. This call is useful to update the QoS object when the underlying socket QoS is being set through a mechanism other than the previous qos () method e.g. inside the dgram_mcast.subscribe () where the QoS for the socket is set through ACE_OS::join_leaf ().
Implements ACE_QoS_Session.
| int ACE_GQoS_Session::update_qos | ( | void | ) | [virtual] |
Calls the ioctl (ACE_SIO_GET_QOS). It is a mechanism of updating the QoS for this session asynchronously, as RSVP events occur.
Implements ACE_QoS_Session.
| ACE_INLINE ACE_QoS_Session::ACE_End_Point_Type ACE_GQoS_Session::flags | ( | void | ) | const [virtual] |
| ACE_INLINE void ACE_GQoS_Session::flags | ( | const ACE_End_Point_Type | flags | ) | [virtual] |
Implements ACE_QoS_Session.
| ACE_INLINE ACE_INET_Addr ACE_GQoS_Session::dest_addr | ( | void | ) | const [virtual] |
| ACE_INLINE void ACE_GQoS_Session::dest_addr | ( | const ACE_INET_Addr & | dest_addr | ) | [virtual] |
| ACE_INLINE u_short ACE_GQoS_Session::source_port | ( | void | ) | const [virtual] |
| ACE_INLINE void ACE_GQoS_Session::source_port | ( | const u_short & | source_port | ) | [virtual] |
| ACE_INLINE ACE_INET_Addr * ACE_GQoS_Session::source_addr | ( | void | ) | const [virtual] |
Implements ACE_QoS_Session.
| ACE_INLINE void ACE_GQoS_Session::source_addr | ( | ACE_INET_Addr * | source_addr | ) | [virtual] |
| ACE_INLINE int ACE_GQoS_Session::session_id | ( | void | ) | const [virtual] |
| ACE_INLINE void ACE_GQoS_Session::session_id | ( | const int | session_id | ) | [virtual] |
| ACE_INLINE ACE_HANDLE ACE_GQoS_Session::rsvp_events_handle | ( | void | ) | [virtual] |
| void ACE_GQoS_Session::rsvp_event_type | ( | ACE_QoS_Session::RSVP_Event_Type | event_type | ) | [virtual] |
Implements ACE_QoS_Session.
| ACE_QoS_Session::RSVP_Event_Type ACE_GQoS_Session::rsvp_event_type | ( | void | ) | [virtual] |
| ACE_INLINE int ACE_GQoS_Session::version | ( | void | ) | [virtual] |
Friends And Related Function Documentation
friend class ACE_QoS_Session_Factory [friend] |
The factory is a friend so it can create this object through the only private constructor.
Member Data Documentation
ACE_BEGIN_VERSIONED_NAMESPACE_DECL ACE_END_VERSIONED_NAMESPACE_DECL ACE_BEGIN_VERSIONED_NAMESPACE_DECL int ACE_GQoS_Session::GQoS_session_id = 0 [static] |
This is a session ID generator. It does a lot more than expected from an int!.
The documentation for this class was generated from the following files:
