| ACE_SOCK_Dgram_Mcast_QoS (options opts=DEFOPTS) |
| Ctor, has same defaults as ACE_SOCK_Dgram_Mcast. More...
|
|
| ~ACE_SOCK_Dgram_Mcast_QoS (void) |
| Default dtor. More...
|
|
int | subscribe (const ACE_INET_Addr &mcast_addr, const ACE_QoS_Params &qos_params, int reuse_addr=1, const ACE_TCHAR *net_if=0, int protocol_family=PF_INET, int protocol=0, ACE_Protocol_Info *protocolinfo=0, ACE_SOCK_GROUP g=0, u_long flags=0, ACE_QoS_Session *qos_session=0) |
|
ssize_t | send (const iovec buffers[], int buffer_count, size_t &number_of_bytes_sent, int flags, const ACE_Addr &addr, ACE_OVERLAPPED *overlapped, ACE_OVERLAPPED_COMPLETION_FUNC func) const |
|
ssize_t | send (const void *buf, size_t n, const ACE_Addr &addr, int flags, ACE_OVERLAPPED *overlapped, ACE_OVERLAPPED_COMPLETION_FUNC func) const |
| Send an n byte buf to the datagram socket (uses <WSASentTo>). More...
|
|
ACE_QoS_Manager | qos_manager (void) |
| Returns the QoS manager for this socket. More...
|
|
int | open (const ACE_INET_Addr &addr, const ACE_QoS_Params &qos_params, int protocol_family=PF_INET, int protocol=0, ACE_Protocol_Info *protocolinfo=0, ACE_SOCK_GROUP g=0, u_long flags=0, int reuse_addr=0) |
|
| ACE_SOCK_Dgram_Mcast (options opts=DEFOPTS) |
|
| ~ACE_SOCK_Dgram_Mcast (void) |
|
int | open (const ACE_INET_Addr &mcast_addr, const ACE_TCHAR *net_if=0, int reuse_addr=1) |
|
int | join (const ACE_INET_Addr &mcast_addr, int reuse_addr=1, const ACE_TCHAR *net_if=0) |
|
int | leave (const ACE_INET_Addr &mcast_addr, const ACE_TCHAR *net_if=0) |
|
ssize_t | send (const void *buf, size_t n, int flags=0) const |
|
ssize_t | send (const iovec iov[], int n, int flags=0) const |
|
int | set_option (int option, char optval) |
|
void | dump (void) const |
|
void | opts (int opts) |
|
int | opts () const |
|
Defines the member functions for the ACE QoS enabled socket wrapper for UDP/IP multicast.
This is a QoS-enabled method for joining a multicast group, which passes <qos_params> via <ACE_OS::join_leaf>. The network interface device driver is instructed to accept datagrams with <mcast_addr> multicast addresses. If the socket has already been opened, <subscribe> closes the socket and opens a new socket bound to the <mcast_addr>. The session object specifies the QoS session that the socket wants to subscribe to. A socket may subscribe to multiple QoS sessions by calling this method multiple times with different session objects.
The <net_if> interface is hardware specific, e.g., use "netstat
-i" to find whether your interface is, such as "le0" or something else. If net_if == 0, <subscribe> uses the default mcast interface. Returns: -1 if the call fails.
Note that some platforms, such as pSoS, support only number, not names, for network interfaces. For these platforms, just give these numbers in alphanumeric form and <subscribe> will convert them into numbers via <ACE_OS::atoi>.
