Specialize TAO_Queued_Message for synchronous requests, i.e. twoways and oneways sent with reliability better than SYNC_NONE. More...

#include <Synch_Queued_Message.h>

Inheritance diagram for TAO_Synch_Queued_Message:

[legend]

Collaboration diagram for TAO_Synch_Queued_Message:

[legend]

Public Member Functions
	TAO_Synch_Queued_Message (const ACE_Message_Block contents, TAO_ORB_Core oc, ACE_Allocator *alloc=0, bool is_heap_allocated=false)
	Constructor.

virtual	~TAO_Synch_Queued_Message ()
	Destructor.

const ACE_Message_Block *	current_block () const

Public Member Functions inherited from TAO_Queued_Message
	TAO_Queued_Message (TAO_ORB_Core oc, ACE_Allocator alloc=0, bool is_heap_allocated=false)
	Constructor.

virtual	~TAO_Queued_Message ()
	Destructor.

TAO_Queued_Message *	next () const
	Set/get the next element in the list.

TAO_Queued_Message *	prev () const
	Set/get the previous element in the list.

void	remove_from_list (TAO_Queued_Message &head, TAO_Queued_Message &tail)
	Remove this element from the list.

void	push_back (TAO_Queued_Message &head, TAO_Queued_Message &tail)
	Insert the current element at the tail of the queue.

void	push_front (TAO_Queued_Message &head, TAO_Queued_Message &tail)
	Insert the current element at the head of the queue.

virtual bool	is_expired (const ACE_Time_Value &now) const
	Check for timeout.

Public Member Functions inherited from TAO_LF_Invocation_Event
	TAO_LF_Invocation_Event ()
	Constructor.

virtual	~TAO_LF_Invocation_Event ()
	Destructor.

Public Member Functions inherited from TAO_LF_Event
	TAO_LF_Event ()
	Constructor.

virtual	~TAO_LF_Event ()
	Destructor.

virtual int	bind (TAO_LF_Follower *follower)
	Bind a follower.

virtual int	unbind (TAO_LF_Follower *follower)
	Unbind the follower.

void	state_changed (LFS_STATE new_state, TAO_Leader_Follower &lf)

bool	successful (TAO_Leader_Follower &lf) const

bool	error_detected (TAO_Leader_Follower &lf) const

bool	keep_waiting (TAO_Leader_Follower &lf) const
	Check if we should keep waiting.

void	reset_state (LFS_STATE new_state)
	Reset the state, irrespective of the previous states.

Implement the Template Methods from TAO_Queued_Message
ACE_Message_Block *	contents_
	The contents of the message.

ACE_Message_Block *	current_block_
	The current message block.

bool	own_contents_
	Do we own the contents_ message block?

virtual size_t	message_length () const
	The contents of the message.

virtual int	all_data_sent () const
	The contents of the message.

virtual void	fill_iov (int iovcnt_max, int &iovcnt, iovec iov[]) const
	The contents of the message.

virtual void	bytes_transferred (size_t &byte_count)
	The contents of the message.

virtual TAO_Queued_Message *	clone (ACE_Allocator *alloc)
	The contents of the message.

virtual void	destroy ()
	The contents of the message.

virtual void	copy_if_necessary (const ACE_Message_Block *chain)
	The contents of the message.

Additional Inherited Members
Public Types inherited from TAO_LF_Event
enum	LFS_STATE { LFS_IDLE = 0 , LFS_ACTIVE , LFS_CONNECTION_WAIT , LFS_SUCCESS , LFS_FAILURE , LFS_TIMEOUT , LFS_CONNECTION_CLOSED }
	The current state. More...

Static Public Member Functions inherited from TAO_LF_Event
static const char *	state_name (LFS_STATE st)
	The current state.

Protected Member Functions inherited from TAO_LF_Invocation_Event
virtual void	state_changed_i (LFS_STATE new_state)
	Validate and perform the state change.

virtual bool	successful_i () const

virtual bool	error_detected_i () const

Protected Member Functions inherited from TAO_LF_Event
bool	keep_waiting_i () const
	Check if we should keep waiting.

Protected Attributes inherited from TAO_Queued_Message
ACE_Allocator *	allocator_
	Cached copy of ORB_Core pointer.

bool const	is_heap_created_
	Cached copy of ORB_Core pointer.

TAO_ORB_Core *	orb_core_
	Cached copy of ORB_Core pointer.

Protected Attributes inherited from TAO_LF_Event
LFS_STATE	state_
	The current state.

TAO_LF_Follower *	follower_
	The bounded follower.

Detailed Description

Specialize TAO_Queued_Message for synchronous requests, i.e. twoways and oneways sent with reliability better than SYNC_NONE.

Reliable requests block the sending thread until the message is sent, likewise, the sending thread must be informed if the connection is closed or the message times out.

In contrast oneway (and AMI) requests sent with the SYNC_NONE policy are simple discarded if the connection fails or they timeout.

Another important difference is the management of the data buffer: one SYNC_NONE messages the buffer is immediately copied into a newly allocated buffer, and must be deallocated. Other types of requests use the memory allocated by the sending thread.

Constructor & Destructor Documentation

◆ TAO_Synch_Queued_Message()

TAO_Synch_Queued_Message::TAO_Synch_Queued_Message	(	const ACE_Message_Block *	contents,
		TAO_ORB_Core *	oc,
		ACE_Allocator *	alloc = 0,
		bool	is_heap_allocated = false )

Constructor.

Parameters

contents	The message block chain that must be sent.
alloc	The allocator that is used to allocate objects of this type.

◆ ~TAO_Synch_Queued_Message()

TAO_Synch_Queued_Message::~TAO_Synch_Queued_Message ( )

virtual

Destructor.

Member Function Documentation

◆ all_data_sent()

int TAO_Synch_Queued_Message::all_data_sent ( ) const

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

◆ bytes_transferred()

void TAO_Synch_Queued_Message::bytes_transferred ( size_t & byte_count )

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

◆ clone()

TAO_Queued_Message * TAO_Synch_Queued_Message::clone ( ACE_Allocator * alloc )

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

◆ copy_if_necessary()

void TAO_Synch_Queued_Message::copy_if_necessary ( const ACE_Message_Block * chain )

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

◆ current_block()

const ACE_Message_Block * TAO_Synch_Queued_Message::current_block ( ) const

◆ destroy()

void TAO_Synch_Queued_Message::destroy ( )

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

◆ fill_iov()

void TAO_Synch_Queued_Message::fill_iov	(	int	iovcnt_max,
		int &	iovcnt,
		iovec	iov[] ) const

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

◆ message_length()

size_t TAO_Synch_Queued_Message::message_length ( ) const

virtual

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

Implements TAO_Queued_Message.

Member Data Documentation

◆ contents_

ACE_Message_Block* TAO_Synch_Queued_Message::contents_

private

The contents of the message.

The message is normally generated by a TAO_OutputCDR stream. The application marshals the payload, possibly generating a chain of message block connected via the 'cont()' field.

◆ current_block_

ACE_Message_Block* TAO_Synch_Queued_Message::current_block_

private

The current message block.

The message may be set in multiple writev() operations. This point keeps track of the next message to send out.

◆ own_contents_

bool TAO_Synch_Queued_Message::own_contents_

private

Do we own the contents_ message block?

This flag differs from the is_heap_allocated_ flag in that it only applies to the contents_ message block and not the TAO_Synch_Queued_Message object itself.

The documentation for this class was generated from the following files:
