CORBA::NVList Class Reference

CORBA::NVList implementation. More...

#include <NVList.h>

Collaboration diagram for CORBA::NVList:

Public Types
typedef NVList_ptr	_ptr_type
typedef NVList_var	_var_type
typedef NVList_out	_out_type

Public Member Functions
ULong	count () const
	return the current number of elements in the list
NamedValue_ptr	add (Flags)
	add an element and just initialize the flags
NamedValue_ptr	add_item (const char *, Flags)
	add an element and initialize its name and flags
NamedValue_ptr	add_value (const char *, const Any &, Flags)
	initializes a value, name, and flags
NamedValue_ptr	add_item_consume (char *, Flags)
NamedValue_ptr	add_value_consume (char *, Any_ptr, Flags)
NamedValue_ptr	item (ULong n)
	retrieve the item at the nth location. Raises Bounds
void	remove (ULong n)
	remove element at index n. Raises Bounds
ULong	_incr_refcount ()
ULong	_decr_refcount ()
void	_tao_incoming_cdr (TAO_InputCDR &cdr, int flag, bool &lazy_evaluation)
void	_tao_encode (TAO_OutputCDR &cdr, int flag)
void	_tao_decode (TAO_InputCDR &cdr, int flag)
	Decode the NVList arguments from the cdr stream.
ptrdiff_t	_tao_target_alignment ()
Boolean	_lazy_has_arguments () const

Static Public Member Functions
static NVList *	_duplicate (NVList *)
static NVList *	_nil ()

Protected Member Functions
	~NVList ()
	Destructor.

Private Member Functions
	NVList ()
NamedValue_ptr	add_element (Flags)
void	evaluate ()

Private Attributes
ACE_Unbounded_Queue< NamedValue_ptr >	values_
	Internal list of parameters stored as NamedValues.
ULong	max_
	Maximum length of list.
std::atomic< uint32_t >	refcount_
	Reference counter.
TAO_SYNCH_MUTEX	lock_
	Protects the incoming pointer.
TAO_InputCDR *	incoming_
int	incoming_flag_

Friends
class	::TAO_NVList_Adapter_Impl
class	Request

Detailed Description

CORBA::NVList implementation.

This is used in the (client side) DII (Dynamic Invocation Interface) to hold parameters, except for the return parameter. It's used in the same role in the (server side) DSI (Dynamic Skeleton Interface).

Each user (client, server) provides the typecode and memory for each parameter using an NVList, then talks to the ORB using a Request or ServerRequest pseudo-object. The ORB copies data to/from the IPC messages (e.g. IIOP::Request, IIOP::Response) as appropriate.

Member Typedef Documentation

_out_type

typedef NVList_out CORBA::NVList::_out_type

_ptr_type

typedef NVList_ptr CORBA::NVList::_ptr_type

_var_type

typedef NVList_var CORBA::NVList::_var_type

Constructor & Destructor Documentation

~NVList()

CORBA::NVList::~NVList ( )

protected

Destructor.

Protected destructor to enforce proper memory management through the reference counting mechanism.

NVList()

CORBA::NVList::NVList ( )

private

Constructor - cannot be instantiated directly other than through the CORBA::ORB::create_list method

Member Function Documentation

_decr_refcount()

CORBA::ULong CORBA::NVList::_decr_refcount

(

)

_duplicate()

CORBA::NVList * CORBA::NVList::_duplicate ( CORBA::NVList * x )

static

_incr_refcount()

CORBA::ULong CORBA::NVList::_incr_refcount

(

)

_lazy_has_arguments()

CORBA::Boolean CORBA::NVList::_lazy_has_arguments

(

)

const

If this list is used by a DII request, this will tell us if our CDR stream contains any marshaled arguments (needed for GIOP 1.2).

_nil()

CORBA::NVList * CORBA::NVList::_nil ( )

static

_tao_decode()

void CORBA::NVList::_tao_decode	(	TAO_InputCDR &	cdr,
		int	flag )

Decode the NVList arguments from the cdr stream.

_tao_encode()

void CORBA::NVList::_tao_encode	(	TAO_OutputCDR &	cdr,
		int	flag )

Encode the NVList into the CDR stream. flag masks the type of arguments (IN, OUT or INOUT) that are to be marshaled.

_tao_incoming_cdr()

void CORBA::NVList::_tao_incoming_cdr	(	TAO_InputCDR &	cdr,
		int	flag,
		bool &	lazy_evaluation )

Set the incoming CDR stream, this is used by TAO to perform lazy evaluation of the NVList in an incoming ServerRequest. The <flag> is used to check which parameters (IN, OUT and/or INOUT) are to be extracted

_tao_target_alignment()

ptrdiff_t CORBA::NVList::_tao_target_alignment

(

)

Return the required alignment to marshal the NVList without any re-alignment. It returns ACE_CDR::MAX_ALIGNMENT to indicate errors.

add()

CORBA::NamedValue_ptr CORBA::NVList::add

(

CORBA::Flags

flags

)

add an element and just initialize the flags

add_element()

CORBA::NamedValue_ptr CORBA::NVList::add_element ( CORBA::Flags flags )

private

Helper to increase the list size. This is used by all the add_ methods of the NVList class

add_item()

CORBA::NamedValue_ptr CORBA::NVList::add_item	(	const char *	name,
		CORBA::Flags	flags )

add an element and initialize its name and flags

add_item_consume()

CORBA::NamedValue_ptr CORBA::NVList::add_item_consume	(	char *	name,
		CORBA::Flags	flags )

just like add_item. In addition, memory management of char * name is taken over by the NVList

add_value()

CORBA::NamedValue_ptr CORBA::NVList::add_value	(	const char *	name,
		const Any &	value,
		CORBA::Flags	flags )

initializes a value, name, and flags

add_value_consume()

CORBA::NamedValue_ptr CORBA::NVList::add_value_consume	(	char *	,
		Any_ptr	,
		Flags	)

just like add_value. In addition, the NVList controls the memory management of the char *name and Any *value parameter

count()

CORBA::ULong CORBA::NVList::count

(

)

const

return the current number of elements in the list

evaluate()

void CORBA::NVList::evaluate ( )

private

Lazy evaluation routine to fill up the Anys in the NVList from the CDR stream.

item()

CORBA::NamedValue_ptr CORBA::NVList::item

(

CORBA::ULong

n

)

retrieve the item at the nth location. Raises Bounds

remove()

void CORBA::NVList::remove

(

CORBA::ULong

n

)

remove element at index n. Raises Bounds

Friends And Related Symbol Documentation

::TAO_NVList_Adapter_Impl

friend class ::TAO_NVList_Adapter_Impl

friend

Request

friend class Request

friend

Member Data Documentation

incoming_

TAO_InputCDR* CORBA::NVList::incoming_

private

When the NVList is used as part of a Server Request we can simply store the CDR buffer and perform lazy evaluation to compute the Anys.

incoming_flag_

int CORBA::NVList::incoming_flag_

private

The flags used to check which parameters are actually extracted from the <incoming_> buffer

lock_

TAO_SYNCH_MUTEX CORBA::NVList::lock_

private

Protects the incoming pointer.

max_

ULong CORBA::NVList::max_

private

Maximum length of list.

refcount_

std::atomic<uint32_t> CORBA::NVList::refcount_

private

Reference counter.

values_

ACE_Unbounded_Queue<NamedValue_ptr> CORBA::NVList::values_

private

Internal list of parameters stored as NamedValues.

---

The documentation for this class was generated from the following files:

• NVList.h
• NVList.cpp
• NVList.inl
