TAO_RT_Stub Class Reference

#include <RT_Stub.h>

Inheritance diagram for TAO_RT_Stub:

Collaboration diagram for TAO_RT_Stub:

Public Member Functions
	TAO_RT_Stub (const char *repository_id, const TAO_MProfile &profiles, TAO_ORB_Core *orb_core)
virtual	~TAO_RT_Stub ()
CORBA::Policy_ptr	get_policy (CORBA::PolicyType type)
CORBA::Policy_ptr	get_cached_policy (TAO_Cached_Policy_Type type)
TAO_Stub *	set_policy_overrides (const CORBA::PolicyList &policies, CORBA::SetOverrideType set_add)
Public Member Functions inherited from TAO_Stub
TAO::Transport_Queueing_Strategy *	transport_queueing_strategy ()
CORBA::ULong	hash (CORBA::ULong maximum)
CORBA::Boolean	is_equivalent (CORBA::Object_ptr other_obj)
	TAO_Stub (const char *repository_id, const TAO_MProfile &profiles, TAO_ORB_Core *orb_core)
void	_incr_refcnt ()
void	_decr_refcnt ()
const TAO_SYNCH_MUTEX &	profile_lock () const
TAO_Profile *	profile_in_use ()
const TAO::ObjectKey &	object_key () const
TAO_MProfile *	make_profiles ()
const TAO_MProfile &	base_profiles () const
TAO_MProfile &	base_profiles ()
const TAO_MProfile *	forward_profiles () const
TAO_MProfile *	forward_profiles ()
TAO_Profile *	next_profile ()
void	reset_profiles ()
CORBA::Boolean	at_starting_profile () const
CORBA::Boolean	valid_forward_profile ()
void	set_valid_profile ()
CORBA::Boolean	valid_profile () const
TAO_Profile *	base_profiles (const TAO_MProfile &mprofiles)
void	add_forward_profiles (const TAO_MProfile &mprofiles, const CORBA::Boolean permanent_forward=false)
CORBA::Boolean	next_profile_retry ()
TAO_ORB_Core *	orb_core () const
CORBA::Boolean	is_collocated () const
void	is_collocated (CORBA::Boolean)
CORBA::ORB_ptr	servant_orb_ptr ()
CORBA::ORB_var &	servant_orb_var ()
void	servant_orb (CORBA::ORB_ptr orb)
void	collocated_servant (TAO_Abstract_ServantBase *servant)
TAO_Abstract_ServantBase *	collocated_servant () const
void	object_proxy_broker (TAO::Object_Proxy_Broker *proxy_broker)
TAO::Object_Proxy_Broker *	object_proxy_broker () const
int	create_ior_info (IOP::IOR *&ior_info, CORBA::ULong &index)
void	destroy ()
CORBA::Boolean	optimize_collocation_objects () const
CORBA::Boolean	marshal (TAO_OutputCDR &)
void	forwarded_on_exception (bool forwarded)
bool	forwarded_on_exception () const

Private Member Functions
void	parse_policies ()
	Helper method used to parse the policies.
void	exposed_priority_model (CORBA::Policy_ptr policy)
void	exposed_priority_banded_connection (CORBA::Policy_ptr policy)
void	exposed_client_protocol (CORBA::Policy_ptr policy)
CORBA::Policy_ptr	exposed_priority_model ()
CORBA::Policy_ptr	exposed_priority_banded_connection ()
CORBA::Policy_ptr	exposed_client_protocol ()
CORBA::Policy_ptr	effective_priority_banded_connection ()
CORBA::Policy_ptr	effective_client_protocol ()
	TAO_RT_Stub (const TAO_RT_Stub &)
TAO_RT_Stub &	operator= (const TAO_RT_Stub &)

Private Attributes
CORBA::Policy_var	priority_model_policy_
CORBA::Policy_var	priority_banded_connection_policy_
CORBA::Policy_var	client_protocol_policy_
bool	are_policies_parsed_

Additional Inherited Members
Public Attributes inherited from TAO_Stub
CORBA::String_var	type_id
Protected Member Functions inherited from TAO_Stub
virtual	~TAO_Stub ()
void	reset_profiles_i ()
TAO_Profile *	next_profile_i ()
Protected Attributes inherited from TAO_Stub
TAO_ORB_Core_Auto_Ptr	orb_core_
CORBA::ORB_var	orb_
CORBA::Boolean	is_collocated_
CORBA::ORB_var	servant_orb_
TAO_Abstract_ServantBase *	collocated_servant_
TAO::Object_Proxy_Broker *	object_proxy_broker_
TAO_MProfile	base_profiles_
TAO_MProfile *	forward_profiles_
TAO_MProfile *	forward_profiles_perm_
TAO_Profile *	profile_in_use_
TAO_SYNCH_MUTEX	profile_lock_
CORBA::Boolean	profile_success_
std::atomic< uint32_t >	refcount_
TAO_Policy_Set *	policies_
IOP::IOR *	ior_info_
IOP::IOR *	forwarded_ior_info_
CORBA::Boolean const	collocation_opt_
std::atomic< bool >	forwarded_on_exception_

Detailed Description

This class represent a stub with extended functionality, which are needed for RTCORBA.

Constructor & Destructor Documentation

TAO_RT_Stub() [1/2]

TAO_RT_Stub::TAO_RT_Stub	(	const char *	repository_id,
		const TAO_MProfile &	profiles,
		TAO_ORB_Core *	orb_core )

~TAO_RT_Stub()

TAO_RT_Stub::~TAO_RT_Stub ( )

virtual

TAO_RT_Stub() [2/2]

TAO_RT_Stub::TAO_RT_Stub ( const TAO_RT_Stub & )

private

Member Function Documentation

effective_client_protocol()

CORBA::Policy_ptr TAO_RT_Stub::effective_client_protocol ( )

private

effective_priority_banded_connection()

CORBA::Policy_ptr TAO_RT_Stub::effective_priority_banded_connection ( )

private

exposed_client_protocol() [1/2]

CORBA::Policy * TAO_RT_Stub::exposed_client_protocol ( )

private

Returns the CORBA::Policy (which will be narrowed and used as RTCORBA::ClientProtocolPolicy) exported in object's IOR.

exposed_client_protocol() [2/2]

void TAO_RT_Stub::exposed_client_protocol ( CORBA::Policy_ptr policy )

private

exposed_priority_banded_connection() [1/2]

CORBA::Policy * TAO_RT_Stub::exposed_priority_banded_connection ( )

private

Returns the CORBA::Policy (which will be narrowed and used as RTCORBA::PriorityBandedConnectionPolicy) exported in object's IOR.

exposed_priority_banded_connection() [2/2]

void TAO_RT_Stub::exposed_priority_banded_connection ( CORBA::Policy_ptr policy )

private

exposed_priority_model() [1/2]

CORBA::Policy * TAO_RT_Stub::exposed_priority_model ( )

private

Returns the CORBA::Policy (which will be narrowed to be used as RTCORBA::PriorityModelPolicy) exported in object's IOR.

exposed_priority_model() [2/2]

void TAO_RT_Stub::exposed_priority_model ( CORBA::Policy_ptr policy )

private

get_cached_policy()

CORBA::Policy_ptr TAO_RT_Stub::get_cached_policy

(

TAO_Cached_Policy_Type

type

)

get_policy()

CORBA::Policy_ptr TAO_RT_Stub::get_policy

(

CORBA::PolicyType

type

)

Returns the effective policy if type is a known client-exposed policy type. Returns the effective override for all other policy types.

operator=()

TAO_RT_Stub & TAO_RT_Stub::operator= ( const TAO_RT_Stub & )

private

parse_policies()

void TAO_RT_Stub::parse_policies ( )

private

Helper method used to parse the policies.

set_policy_overrides()

TAO_Stub * TAO_RT_Stub::set_policy_overrides	(	const CORBA::PolicyList &	policies,
		CORBA::SetOverrideType	set_add )

Member Data Documentation

are_policies_parsed_

bool TAO_RT_Stub::are_policies_parsed_

private

client_protocol_policy_

CORBA::Policy_var TAO_RT_Stub::client_protocol_policy_

private

priority_banded_connection_policy_

CORBA::Policy_var TAO_RT_Stub::priority_banded_connection_policy_

private

priority_model_policy_

CORBA::Policy_var TAO_RT_Stub::priority_model_policy_

private

---

The documentation for this class was generated from the following files:

• RT_Stub.h
• RT_Stub.cpp
