ACE
6.2.5
|
Defines the interface for a service that exchanges data with its connected peer and supports buffering. More...
#include <Svc_Handler.h>
Public Member Functions | |
ACE_Buffered_Svc_Handler (ACE_Thread_Manager *thr_mgr=0, ACE_Message_Queue< SYNCH_TRAITS > *mq=0, ACE_Reactor *reactor=ACE_Reactor::instance(), size_t max_buffer_size=0, ACE_Time_Value *relative_timeout=0) | |
virtual | ~ACE_Buffered_Svc_Handler (void) |
Destructor, which calls <flush>. More... | |
virtual int | put (ACE_Message_Block *message_block, ACE_Time_Value *timeout=0) |
virtual int | flush (void) |
virtual int | handle_timeout (const ACE_Time_Value &time, const void *) |
void | dump (void) const |
Dump the state of an object. More... | |
![]() | |
ACE_Svc_Handler (ACE_Thread_Manager *thr_mgr=0, ACE_Message_Queue< SYNCH_TRAITS > *mq=0, ACE_Reactor *reactor=ACE_Reactor::instance()) | |
virtual | ~ACE_Svc_Handler (void) |
Destructor. More... | |
virtual int | open (void *acceptor_or_connector=0) |
virtual int | close (u_long flags=0) |
virtual int | idle (u_long flags=0) |
virtual ACE_Recyclable_State | recycle_state (void) const |
virtual int | recycle_state (ACE_Recyclable_State new_state) |
virtual void | cleanup_hint (void **act_holder=0) |
virtual int | init (int argc, ACE_TCHAR *argv[]) |
virtual int | fini (void) |
virtual int | info (ACE_TCHAR **info_string, size_t length) const |
virtual int | handle_close (ACE_HANDLE=ACE_INVALID_HANDLE, ACE_Reactor_Mask=ACE_Event_Handler::ALL_EVENTS_MASK) |
virtual ACE_HANDLE | get_handle (void) const |
Get the underlying handle associated with the <peer_>. More... | |
virtual void | set_handle (ACE_HANDLE) |
Set the underlying handle associated with the <peer_>. More... | |
PEER_STREAM & | peer (void) const |
void * | operator new (size_t n) |
void * | operator new (size_t n, void *p) |
This operator permits "placement new" on a per-object basis. More... | |
virtual void | destroy (void) |
void | operator delete (void *) |
void | operator delete (void *, void *) |
void | shutdown (void) |
Close down the descriptor and unregister from the Reactor. More... | |
void | dump (void) const |
Dump the state of an object. More... | |
virtual void | recycler (ACE_Connection_Recycling_Strategy *recycler, const void *recycling_act) |
virtual ACE_Connection_Recycling_Strategy * | recycler (void) const |
Get the recycler. More... | |
virtual const void * | recycling_act (void) const |
Get the recycling act. More... | |
virtual int | recycle (void *=0) |
![]() | |
ACE_Task (ACE_Thread_Manager *thr_mgr=0, ACE_Message_Queue< ACE_SYNCH_USE, ACE_System_Time_Policy > *mq=0) | |
virtual | ~ACE_Task (void) |
Destructor. More... | |
ACE_Message_Queue < ACE_SYNCH_USE, ACE_System_Time_Policy > * | msg_queue (void) |
Gets the message queue associated with this task. More... | |
void | msg_queue (ACE_Message_Queue< ACE_SYNCH_USE, ACE_System_Time_Policy > *) |
Sets the message queue associated with this task. More... | |
ACE_Time_Value_T < ACE_System_Time_Policy > | gettimeofday (void) const |
void | set_time_policy (ACE_System_Time_Policyconst &time_policy) |
int | putq (ACE_Message_Block *, ACE_Time_Value *timeout=0) |
int | getq (ACE_Message_Block *&mb, ACE_Time_Value *timeout=0) |
int | ungetq (ACE_Message_Block *, ACE_Time_Value *timeout=0) |
int | reply (ACE_Message_Block *mb, ACE_Time_Value *tv=0) |
int | put_next (ACE_Message_Block *msg, ACE_Time_Value *timeout=0) |
const ACE_TCHAR * | name (void) const |
ACE_Task< ACE_SYNCH_USE, ACE_System_Time_Policy > * | next (void) |
Get next Task pointer. More... | |
void | next (ACE_Task< ACE_SYNCH_USE, ACE_System_Time_Policy > *) |
Set next Task pointer. More... | |
ACE_Task< ACE_SYNCH_USE, ACE_System_Time_Policy > * | sibling (void) |
ACE_Module< ACE_SYNCH_USE, ACE_System_Time_Policy > * | module (void) const |
Return the Task's Module if there is one, else returns 0. More... | |
int | flush (u_long flag=ACE_Task_Flags::ACE_FLUSHALL) |
void | water_marks (ACE_IO_Cntl_Msg::ACE_IO_Cntl_Cmds, size_t) |
Manipulate watermarks. More... | |
void | dump (void) const |
Dump the state of an object. More... | |
![]() | |
ACE_Task_Base (ACE_Thread_Manager *=0) | |
Constructor. More... | |
virtual | ~ACE_Task_Base (void) |
Destructor. More... | |
virtual int | module_closed (void) |
virtual int | svc (void) |
Run by a daemon thread to handle deferred processing. More... | |
virtual int | activate (long flags=THR_NEW_LWP|THR_JOINABLE|THR_INHERIT_SCHED, int n_threads=1, int force_active=0, long priority=ACE_DEFAULT_THREAD_PRIORITY, int grp_id=-1, ACE_Task_Base *task=0, ACE_hthread_t thread_handles[]=0, void *stack[]=0, size_t stack_size[]=0, ACE_thread_t thread_ids[]=0, const char *thr_name[]=0) |
virtual int | wait (void) |
Wait for all threads running in a task to exit. More... | |
virtual int | suspend (void) |
Suspend a task. More... | |
virtual int | resume (void) |
Resume a suspended task. More... | |
int | grp_id (void) const |
Get the current group id. More... | |
void | grp_id (int) |
Set the current group id. More... | |
ACE_Thread_Manager * | thr_mgr (void) const |
Get the thread manager associated with this Task. More... | |
void | thr_mgr (ACE_Thread_Manager *) |
Set the thread manager associated with this Task. More... | |
int | is_reader (void) const |
True if queue is a reader, else false. More... | |
int | is_writer (void) const |
True if queue is a writer, else false. More... | |
size_t | thr_count (void) const |
ACE_thread_t | last_thread (void) const |
![]() | |
ACE_Service_Object (ACE_Reactor *=0) | |
Constructor. More... | |
virtual | ~ACE_Service_Object (void) |
Destructor. More... | |
![]() | |
virtual | ~ACE_Event_Handler (void) |
Destructor is virtual to enable proper cleanup. More... | |
virtual int | priority (void) const |
virtual void | priority (int priority) |
Set the priority of the Event_Handler. More... | |
virtual int | handle_input (ACE_HANDLE fd=ACE_INVALID_HANDLE) |
Called when input events occur (e.g., connection or data). More... | |
virtual int | handle_output (ACE_HANDLE fd=ACE_INVALID_HANDLE) |
virtual int | handle_exception (ACE_HANDLE fd=ACE_INVALID_HANDLE) |
Called when an exceptional events occur (e.g., SIGURG). More... | |
virtual int | handle_exit (ACE_Process *) |
Called when a process exits. More... | |
virtual int | handle_signal (int signum, siginfo_t *=0, ucontext_t *=0) |
virtual int | resume_handler (void) |
virtual int | handle_qos (ACE_HANDLE=ACE_INVALID_HANDLE) |
virtual int | handle_group_qos (ACE_HANDLE=ACE_INVALID_HANDLE) |
virtual void | reactor (ACE_Reactor *reactor) |
Set the event demultiplexors. More... | |
virtual ACE_Reactor * | reactor (void) const |
Get the event demultiplexors. More... | |
virtual ACE_Reactor_Timer_Interface * | reactor_timer_interface (void) const |
Get only the reactor's timer related interface. More... | |
virtual Reference_Count | add_reference (void) |
Increment reference count on the handler. More... | |
virtual Reference_Count | remove_reference (void) |
Decrement reference count on the handler. More... | |
Reference_Counting_Policy & | reference_counting_policy (void) |
Current Reference_Counting_Policy. More... | |
![]() | |
ACE_Shared_Object (void) | |
Constructor. More... | |
virtual | ~ACE_Shared_Object (void) |
Destructor. More... | |
Protected Member Functions | |
virtual int | flush_i (void) |
![]() | |
ACE_Event_Handler (ACE_Reactor *=0, int priority=ACE_Event_Handler::LO_PRIORITY) | |
Force ACE_Event_Handler to be an abstract base class. More... | |
Protected Attributes | |
size_t | maximum_buffer_size_ |
size_t | current_buffer_size_ |
Current size in bytes of the <Message_Queue> contents. More... | |
ACE_Time_Value | next_timeout_ |
Timeout value used to control when the buffer is flushed. More... | |
ACE_Time_Value | interval_ |
Interval of the timeout. More... | |
ACE_Time_Value * | timeoutp_ |
Timeout pointer. More... | |
![]() | |
PEER_STREAM | peer_ |
Maintain connection with client. More... | |
bool | dynamic_ |
Have we been dynamically created? More... | |
bool | closing_ |
ACE_Connection_Recycling_Strategy * | recycler_ |
Pointer to the connection recycler. More... | |
const void * | recycling_act_ |
![]() | |
size_t | thr_count_ |
ACE_Thread_Manager * | thr_mgr_ |
Multi-threading manager. More... | |
u_long | flags_ |
ACE_Task flags. More... | |
int | grp_id_ |
This maintains the group id of the Task. More... | |
ACE_thread_t | last_thread_id_ |
Holds the thread ID of the last thread to exit svc() in this object. More... | |
![]() | |
Atomic_Reference_Count | reference_count_ |
Reference count. More... | |
Additional Inherited Members | |
![]() | |
typedef PEER_STREAM::PEER_ADDR | addr_type |
typedef PEER_STREAM | stream_type |
![]() | |
enum | { LO_PRIORITY = 0, HI_PRIORITY = 10, NULL_MASK = 0, READ_MASK = (1 << 0), WRITE_MASK = (1 << 1), EXCEPT_MASK = (1 << 2), ACCEPT_MASK = (1 << 3), CONNECT_MASK = (1 << 4), TIMER_MASK = (1 << 5), QOS_MASK = (1 << 6), GROUP_QOS_MASK = (1 << 7), SIGNAL_MASK = (1 << 8), ALL_EVENTS_MASK, RWE_MASK, DONT_CALL = (1 << 9) } |
enum | { ACE_EVENT_HANDLER_NOT_RESUMED = -1, ACE_REACTOR_RESUMES_HANDLER = 0, ACE_APPLICATION_RESUMES_HANDLER } |
typedef long | Reference_Count |
Reference count type. More... | |
![]() | |
static ACE_THR_FUNC_RETURN | svc_run (void *) |
Routine that runs the service routine as a daemon thread. More... | |
static void | cleanup (void *object, void *params) |
![]() | |
static ACE_THR_FUNC_RETURN | read_adapter (void *event_handler) |
static int | register_stdin_handler (ACE_Event_Handler *eh, ACE_Reactor *reactor, ACE_Thread_Manager *thr_mgr, int flags=THR_DETACHED) |
static int | remove_stdin_handler (ACE_Reactor *reactor, ACE_Thread_Manager *thr_mgr) |
Performs the inverse of the register_stdin_handler() method. More... | |
![]() | |
ACE_Message_Queue < ACE_SYNCH_USE, ACE_System_Time_Policy > * | msg_queue_ |
Queue of messages on the ACE_Task.. More... | |
bool | delete_msg_queue_ |
true if should delete Message_Queue, false otherwise. More... | |
ACE_Module< ACE_SYNCH_USE, ACE_System_Time_Policy > * | mod_ |
Back-pointer to the enclosing module. More... | |
ACE_Task< ACE_SYNCH_USE, ACE_System_Time_Policy > * | next_ |
Pointer to adjacent ACE_Task. More... | |
ACE_ALLOC_HOOK_DECLARE | |
Declare the dynamic allocation hooks. More... | |
![]() | |
typedef ACE_Atomic_Op < ACE_SYNCH_MUTEX, Reference_Count > | Atomic_Reference_Count |
Typedef for implementation of reference counting. More... | |
Defines the interface for a service that exchanges data with its connected peer and supports buffering.
The buffering feature makes it possible to queue up ACE_Message_Blocks in an ACE_Message_Queue until (1) the queue is "full" or (2) a period of time elapses, at which point the queue is "flushed" via <sendv_n> to the peer.
ACE_Buffered_Svc_Handler< PEER_STREAM, SYNCH_TRAITS >::ACE_Buffered_Svc_Handler | ( | ACE_Thread_Manager * | thr_mgr = 0 , |
ACE_Message_Queue< SYNCH_TRAITS > * | mq = 0 , |
||
ACE_Reactor * | reactor = ACE_Reactor::instance () , |
||
size_t | max_buffer_size = 0 , |
||
ACE_Time_Value * | relative_timeout = 0 |
||
) |
Constructor initializes the thr_mgr and mq by passing them down to the ACE_Task base class. The reactor is passed to the ACE_Event_Handler. The max_buffer_size and relative_timeout are used to determine at what point to flush the mq. By default, there's no buffering at all. The relative_timeout value is interpreted to be in a unit that's relative to the current time returned by <ACE_OS::gettimeofday>.
|
virtual |
Destructor, which calls <flush>.
void ACE_Buffered_Svc_Handler< PEER_STREAM, SYNCH_TRAITS >::dump | ( | void | ) | const |
Dump the state of an object.
|
virtual |
Flush the ACE_Message_Queue, which writes all the queued ACE_Message_Blocks to the <PEER_STREAM>.
|
protectedvirtual |
Implement the flush operation on the ACE_Message_Queue, which writes all the queued ACE_Message_Blocks to the <PEER_STREAM>. Assumes that the caller holds the lock.
|
virtual |
This method is not currently implemented – this is where the integration with the <Reactor> would occur.
Reimplemented from ACE_Svc_Handler< PEER_STREAM, SYNCH_TRAITS >.
|
virtual |
Insert the ACE_Message_Block chain rooted at message_block into the ACE_Message_Queue with the designated timeout. The <flush> method will be called if this <put> causes the number of bytes to exceed the maximum buffer size or if the timeout period has elapsed.
Reimplemented from ACE_Task_Base.
|
protected |
Current size in bytes of the <Message_Queue> contents.
|
protected |
Interval of the timeout.
|
protected |
Maximum size the <Message_Queue> can be before we have to flush the buffer.
|
protected |
Timeout value used to control when the buffer is flushed.
|
protected |
Timeout pointer.
