#include <EC_Event_Channel_Base.h>
This class is the Mediator between all the classes in the EC implementation, its main task is to redirect the messages to the right components, to hold and manage the lifetime of the long lived objects (Timer_Module, SupplierAdmin, ConsumerAdmin and Dispatching) and to provide a simpler interface to the EC_Factory.
anonymous enum [protected] |
TAO_EC_Event_Channel_Base::~TAO_EC_Event_Channel_Base | ( | void | ) | [virtual] |
destructor
TAO_BEGIN_VERSIONED_NAMESPACE_DECL TAO_EC_Event_Channel_Base::TAO_EC_Event_Channel_Base | ( | const TAO_EC_Event_Channel_Attributes & | attributes, | |
TAO_EC_Factory * | factory = 0 , |
|||
int | own_factory = 0 | |||
) | [protected] |
Constructor If own_factory is not 0 it assumes ownership of the factory. If the factory is nil it uses the Service_Configurator to load the Factory, if not found it uses TAO_EC_Default_Resource_Factory
void TAO_EC_Event_Channel_Base::activate | ( | void | ) | [virtual] |
Start the internal threads (if any), etc. After this call the EC can be used.
void TAO_EC_Event_Channel_Base::shutdown | ( | void | ) | [virtual] |
Shutdown any internal threads, cleanup all the internal structures, flush all the messages, etc.
void TAO_EC_Event_Channel_Base::for_each_consumer | ( | TAO_ESF_Worker< TAO_EC_ProxyPushSupplier > * | worker | ) | [virtual] |
void TAO_EC_Event_Channel_Base::for_each_supplier | ( | TAO_ESF_Worker< TAO_EC_ProxyPushConsumer > * | worker | ) | [virtual] |
ACE_INLINE TAO_EC_Dispatching * TAO_EC_Event_Channel_Base::dispatching | ( | void | ) | const |
Access the dispatching module....
ACE_INLINE TAO_EC_Filter_Builder * TAO_EC_Event_Channel_Base::filter_builder | ( | void | ) | const |
Access the filter builder....
ACE_INLINE TAO_EC_Supplier_Filter_Builder * TAO_EC_Event_Channel_Base::supplier_filter_builder | ( | void | ) | const |
Access the filter builder....
ACE_INLINE TAO_EC_ConsumerAdmin * TAO_EC_Event_Channel_Base::consumer_admin | ( | void | ) | const |
Access the consumer admin implementation, useful for controlling the activation...
ACE_INLINE TAO_EC_SupplierAdmin * TAO_EC_Event_Channel_Base::supplier_admin | ( | void | ) | const |
Access the supplier admin implementation, useful for controlling the activation...
ACE_INLINE TAO_EC_Timeout_Generator * TAO_EC_Event_Channel_Base::timeout_generator | ( | void | ) | const |
Access the timer module...
ACE_INLINE TAO_EC_Scheduling_Strategy * TAO_EC_Event_Channel_Base::scheduling_strategy | ( | void | ) | const |
Access the scheduling strategy.
ACE_INLINE TAO_EC_ConsumerControl * TAO_EC_Event_Channel_Base::consumer_control | ( | void | ) | const |
Access the client control strategies.
ACE_INLINE TAO_EC_SupplierControl * TAO_EC_Event_Channel_Base::supplier_control | ( | void | ) | const |
ACE_INLINE void TAO_EC_Event_Channel_Base::create_proxy | ( | TAO_EC_ProxyPushSupplier *& | x | ) |
Create and destroy a ProxyPushSupplier.
ACE_INLINE void TAO_EC_Event_Channel_Base::destroy_proxy | ( | TAO_EC_ProxyPushSupplier * | supplier | ) |
ACE_INLINE void TAO_EC_Event_Channel_Base::create_proxy | ( | TAO_EC_ProxyPushConsumer *& | x | ) |
Create and destroy a ProxyPushConsumer.
ACE_INLINE void TAO_EC_Event_Channel_Base::destroy_proxy | ( | TAO_EC_ProxyPushConsumer * | consumer | ) |
ACE_INLINE void TAO_EC_Event_Channel_Base::create_proxy_collection | ( | TAO_EC_ProxyPushSupplier_Collection *& | x | ) |
Create and destroy a the collections used to store ProxyPushSuppliers
ACE_INLINE void TAO_EC_Event_Channel_Base::destroy_proxy_collection | ( | TAO_EC_ProxyPushSupplier_Collection * | x | ) |
ACE_INLINE void TAO_EC_Event_Channel_Base::create_proxy_collection | ( | TAO_EC_ProxyPushConsumer_Collection *& | x | ) |
Create and destroy a the collections used to store ProxyPushConsumers
ACE_INLINE void TAO_EC_Event_Channel_Base::destroy_proxy_collection | ( | TAO_EC_ProxyPushConsumer_Collection * | x | ) |
ACE_INLINE PortableServer::POA_ptr TAO_EC_Event_Channel_Base::supplier_poa | ( | void | ) |
Access the supplier and consumer POAs from the factory.
ACE_INLINE PortableServer::POA_ptr TAO_EC_Event_Channel_Base::consumer_poa | ( | void | ) |
ACE_INLINE ACE_Lock * TAO_EC_Event_Channel_Base::create_consumer_lock | ( | void | ) |
Locking strategies for the ProxyPushConsumer and ProxyPushSupplier objects
ACE_INLINE void TAO_EC_Event_Channel_Base::destroy_consumer_lock | ( | ACE_Lock * | x | ) |
ACE_INLINE ACE_Lock * TAO_EC_Event_Channel_Base::create_supplier_lock | ( | void | ) |
ACE_INLINE void TAO_EC_Event_Channel_Base::destroy_supplier_lock | ( | ACE_Lock * | x | ) |
void TAO_EC_Event_Channel_Base::connected | ( | TAO_EC_ProxyPushConsumer * | consumer | ) | [virtual] |
Used to inform the EC that a Consumer has connected or disconnected from it.
void TAO_EC_Event_Channel_Base::reconnected | ( | TAO_EC_ProxyPushConsumer * | consumer | ) | [virtual] |
void TAO_EC_Event_Channel_Base::disconnected | ( | TAO_EC_ProxyPushConsumer * | consumer | ) | [virtual] |
void TAO_EC_Event_Channel_Base::connected | ( | TAO_EC_ProxyPushSupplier * | supplier | ) | [virtual] |
Used to inform the EC that a Supplier has connected or disconnected from it.
void TAO_EC_Event_Channel_Base::reconnected | ( | TAO_EC_ProxyPushSupplier * | supplier | ) | [virtual] |
void TAO_EC_Event_Channel_Base::disconnected | ( | TAO_EC_ProxyPushSupplier * | supplier | ) | [virtual] |
ACE_INLINE int TAO_EC_Event_Channel_Base::consumer_reconnect | ( | void | ) | const |
Can the consumers reconnect to the EC?
ACE_INLINE int TAO_EC_Event_Channel_Base::supplier_reconnect | ( | void | ) | const |
Can the suppliers reconnect to the EC?
ACE_INLINE int TAO_EC_Event_Channel_Base::disconnect_callbacks | ( | void | ) | const |
Should we send callback disconnect messages when a proxy is disconnected by the client
ACE_INLINE CORBA::Object_ptr TAO_EC_Event_Channel_Base::scheduler | ( | void | ) |
Obtain the scheduler, the user must release.
RtecEventChannelAdmin::ConsumerAdmin_ptr TAO_EC_Event_Channel_Base::for_consumers | ( | void | ) | [virtual] |
The default implementation is: this->consumer_admin ()->_this ();
RtecEventChannelAdmin::SupplierAdmin_ptr TAO_EC_Event_Channel_Base::for_suppliers | ( | void | ) | [virtual] |
The default implementation is: this->supplier_admin ()->_this ();
void TAO_EC_Event_Channel_Base::destroy | ( | void | ) | [virtual] |
Commit suicide.
RtecEventChannelAdmin::Observer_Handle TAO_EC_Event_Channel_Base::append_observer | ( | RtecEventChannelAdmin::Observer_ptr | observer | ) | [virtual] |
void TAO_EC_Event_Channel_Base::remove_observer | ( | RtecEventChannelAdmin::Observer_Handle | handle | ) | [virtual] |
ACE_INLINE int TAO_EC_Event_Channel_Base::destroyed | ( | void | ) |
Return 1 if the event channel is already destroyed.
ACE_INLINE TAO_EC_Factory * TAO_EC_Event_Channel_Base::factory | ( | void | ) | const [protected] |
Get the factory.
ACE_INLINE void TAO_EC_Event_Channel_Base::factory | ( | TAO_EC_Factory * | factory, | |
int | own_factory = 0 | |||
) | [protected] |
Set the factory, if own_factory is not 0 it assumes ownership of the factory.
void TAO_EC_Event_Channel_Base::create_strategies | ( | void | ) | [protected] |
Create all strategies
void TAO_EC_Event_Channel_Base::deactivate_supplier_admin | ( | void | ) | [protected] |
Helpers. Deactivate admins from their POAs, ignoring any CORBA exceptions.
void TAO_EC_Event_Channel_Base::deactivate_consumer_admin | ( | void | ) | [protected] |
Helpers. Deactivate admins from their POAs, ignoring any CORBA exceptions.
The POAs used to activate "supplier-side" and "consumer-side" objects.
TAO_EC_Factory* TAO_EC_Event_Channel_Base::factory_ [protected] |
This is the abstract factory that creates all the objects that compose an event channel, the event channel simply acts as a Mediator among them.
int TAO_EC_Event_Channel_Base::own_factory_ [protected] |
Flag that indicates if we own the factory.
The dispatching "module".
The filter builder.
The filter builder for suppliers.
The ConsumerAdmin implementation.
The SupplierAdmin implementation.
The timeout generator.
The observer strategy.
The scheduler (may be nil).
The scheduling strategy.
int TAO_EC_Event_Channel_Base::consumer_reconnect_ [protected] |
Consumer reconnection flags.
int TAO_EC_Event_Channel_Base::supplier_reconnect_ [protected] |
Supplier reconnection flags.
int TAO_EC_Event_Channel_Base::disconnect_callbacks_ [protected] |
If not zero we send callbacks when a proxy is disconnected.
Strategies to disconnect misbehaving or destroyed consumers.
Strategies to disconnect misbehaving or destroyed suppliers.
TAO_SYNCH_MUTEX TAO_EC_Event_Channel_Base::mutex_ [protected] |
Mutex to protect the internal state.
int TAO_EC_Event_Channel_Base::status_ [protected] |
