ACE_MEM_Acceptor Class Reference

Defines the format and interface for the acceptor side of the local mmap stream. More...

#include <MEM_Acceptor.h>

Inheritance diagram for ACE_MEM_Acceptor:

Collaboration diagram for ACE_MEM_Acceptor:

Public Types
typedef ACE_MEM_Addr	PEER_ADDR
typedef ACE_MEM_Stream	PEER_STREAM
Public Types inherited from ACE_SOCK_Acceptor
typedef ACE_INET_Addr	PEER_ADDR
typedef ACE_SOCK_Stream	PEER_STREAM

Public Member Functions
	ACE_MEM_Acceptor ()
	Default constructor.
	~ACE_MEM_Acceptor ()
	Destructor.
	ACE_MEM_Acceptor (const ACE_MEM_Addr &remote_sap, int reuse_addr=0, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0)
	Initiate a passive mode socket.
int	open (const ACE_MEM_Addr &local_sap, int reuse_addr=0, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0)
int	accept (ACE_MEM_Stream &new_ipc_sap, ACE_MEM_Addr *remote_addr=0, ACE_Time_Value *timeout=0, bool restart=true, bool reset_new_handle=false)
	Accept a new data transfer connection.
int	shared_accept_finish (ACE_MEM_Stream new_stream, int in_blocking_mode, bool reset_new_handle) const
const ACE_TCHAR *	mmap_prefix () const
void	mmap_prefix (const ACE_TCHAR *prefix)
void	init_buffer_size (ACE_OFF_T bytes)
ACE_MEM_IO::Signal_Strategy	preferred_strategy () const
	Get the preferred signaling strategy.
void	preferred_strategy (ACE_MEM_IO::Signal_Strategy strategy)
	Set the preferred signaling strategy.
int	get_local_addr (ACE_MEM_Addr &) const
void	dump () const
	Dump the state of an object.
Public Member Functions inherited from ACE_SOCK_Acceptor
	ACE_SOCK_Acceptor ()
	Default constructor.
	ACE_SOCK_Acceptor (const ACE_Addr &local_sap, int reuse_addr=0, int protocol_family=PF_UNSPEC, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0, int ipv6_only=0)
	ACE_SOCK_Acceptor (const ACE_Addr &local_sap, ACE_Protocol_Info *protocolinfo, ACE_SOCK_GROUP g, u_long flags, int reuse_addr, int protocol_family=PF_UNSPEC, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0, int ipv6_only=0)
	Initialize a passive-mode QoS-enabled acceptor socket.
int	open (const ACE_Addr &local_sap, int reuse_addr=0, int protocol_family=PF_UNSPEC, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0, int ipv6_only=0)
int	open (const ACE_Addr &local_sap, ACE_Protocol_Info *protocolinfo, ACE_SOCK_GROUP g, u_long flags, int reuse_addr, int protocol_family=PF_UNSPEC, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0, int ipv6_only=0)
int	close ()
	Close the socket. Returns 0 on success and -1 on failure.
	~ACE_SOCK_Acceptor ()
	Default dtor.
int	accept (ACE_SOCK_Stream &new_stream, ACE_Addr *remote_addr=0, ACE_Time_Value *timeout=0, bool restart=true, bool reset_new_handle=false) const
int	accept (ACE_SOCK_Stream &new_stream, ACE_Accept_QoS_Params qos_params, ACE_Addr *remote_addr=0, ACE_Time_Value *timeout=0, bool restart=true, bool reset_new_handle=false) const
void	dump () const
	Dump the state of an object.
Public Member Functions inherited from ACE_SOCK
int	set_option (int level, int option, void *optval, int optlen) const
	Wrapper around the setsockopt system call.
int	get_option (int level, int option, void *optval, int *optlen) const
	Wrapper around the getsockopt system call.
int	close ()
int	get_local_addr (ACE_Addr &) const
int	get_remote_addr (ACE_Addr &) const
void	dump () const
	Dump the state of an object.
int	open (int type, int protocol_family, int protocol, int reuse_addr)
	Wrapper around the BSD-style socket system call (no QoS).
int	open (int type, int protocol_family, int protocol, ACE_Protocol_Info *protocolinfo, ACE_SOCK_GROUP g, u_long flags, int reuse_addr)
	Wrapper around the QoS-enabled WSASocket function.
Public Member Functions inherited from ACE_IPC_SAP
int	control (int cmd, void *) const
	Interface for <ioctl>.
int	enable (int value) const
int	disable (int value) const
ACE_HANDLE	get_handle () const
	Get the underlying handle.
void	set_handle (ACE_HANDLE handle)
	Set the underlying handle.
void	dump () const
	Dump the state of an object.

Public Attributes
	ACE_ALLOC_HOOK_DECLARE
	Declare the dynamic allocation hooks.
Public Attributes inherited from ACE_SOCK_Acceptor
	ACE_ALLOC_HOOK_DECLARE
	Declare the dynamic allocation hooks.
Public Attributes inherited from ACE_SOCK
	ACE_ALLOC_HOOK_DECLARE
	Declare the dynamic allocation hooks.
Public Attributes inherited from ACE_IPC_SAP
	ACE_ALLOC_HOOK_DECLARE
	Declare the dynamic allocation hooks.

Protected Member Functions
int	open (const ACE_Addr &local_sap, int reuse_addr=0, int protocol_family=PF_INET, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0)
int	open (const ACE_Addr &local_sap, ACE_Protocol_Info *protocolinfo, ACE_SOCK_GROUP g, u_long flags, int reuse_addr, int protocol_family, int backlog=ACE_DEFAULT_BACKLOG, int protocol=0)
int	accept (ACE_SOCK_Stream &new_stream, ACE_Addr *remote_addr=0, ACE_Time_Value *timeout=0, bool restart=true, bool reset_new_handle=false) const
int	accept (ACE_SOCK_Stream &new_stream, ACE_Accept_QoS_Params qos_params, ACE_Addr *remote_addr=0, ACE_Time_Value *timeout=0, bool restart=true, bool reset_new_handle=false) const
Protected Member Functions inherited from ACE_SOCK_Acceptor
int	shared_accept_start (ACE_Time_Value *timeout, bool restart, int &in_blocking_mode) const
int	shared_accept_finish (ACE_SOCK_Stream new_stream, int in_blocking_mode, bool reset_new_handle) const
int	shared_open (const ACE_Addr &local_sap, int protocol_family, int backlog, int ipv6_only)
Protected Member Functions inherited from ACE_SOCK
	ACE_SOCK (int type, int protocol_family, int protocol=0, int reuse_addr=0)
	ACE_SOCK (int type, int protocol_family, int protocol, ACE_Protocol_Info *protocolinfo, ACE_SOCK_GROUP g, u_long flags, int reuse_addr)
	ACE_SOCK ()
	~ACE_SOCK ()=default
	Protected destructor.
Protected Member Functions inherited from ACE_IPC_SAP
	ACE_IPC_SAP ()
	Default constructor.
	~ACE_IPC_SAP ()
	Protected destructor.

Private Attributes
ACE_TCHAR *	mmap_prefix_
ACE_MEM_SAP::MALLOC_OPTIONS	malloc_options_
ACE_MEM_IO::Signal_Strategy	preferred_strategy_
	Preferred signaling strategy.

Detailed Description

Defines the format and interface for the acceptor side of the local mmap stream.

This class should be modified to prevent user passing a non-localhost endpoint as the acceptor listen point because it doesn't make any sense at all to make the listening endpoint visible (or connectable) anywhere outside of this machine. However, the type of endpoint is left as <ACE_Addr> so we can later changed to use UNIX-domain sockets with mmap stream if so desired. (Currently, using UNIX-domain sockets, i.e., ACE_LSOCK_*, with this class will not work.)

Member Typedef Documentation

PEER_ADDR

typedef ACE_MEM_Addr ACE_MEM_Acceptor::PEER_ADDR

PEER_STREAM

typedef ACE_MEM_Stream ACE_MEM_Acceptor::PEER_STREAM

Constructor & Destructor Documentation

ACE_MEM_Acceptor() [1/2]

ACE_MEM_Acceptor::ACE_MEM_Acceptor

(

)

Default constructor.

~ACE_MEM_Acceptor()

ACE_MEM_Acceptor::~ACE_MEM_Acceptor

(

)

Destructor.

ACE_MEM_Acceptor() [2/2]

ACE_MEM_Acceptor::ACE_MEM_Acceptor	(	const ACE_MEM_Addr &	remote_sap,
		int	reuse_addr = 0,
		int	backlog = ACE_DEFAULT_BACKLOG,
		int	protocol = 0 )

Initiate a passive mode socket.

Member Function Documentation

accept() [1/3]

int ACE_MEM_Acceptor::accept	(	ACE_MEM_Stream &	new_ipc_sap,
		ACE_MEM_Addr *	remote_addr = 0,
		ACE_Time_Value *	timeout = 0,
		bool	restart = true,
		bool	reset_new_handle = false )

Accept a new data transfer connection.

accept() [2/3]

int ACE_MEM_Acceptor::accept ( ACE_SOCK_Stream & new_stream, ACE_Accept_QoS_Params qos_params, ACE_Addr * remote_addr = 0, ACE_Time_Value * timeout = 0, bool restart = true, bool reset_new_handle = false ) const

inlineprotected

accept() [3/3]

int ACE_MEM_Acceptor::accept ( ACE_SOCK_Stream & new_stream, ACE_Addr * remote_addr = 0, ACE_Time_Value * timeout = 0, bool restart = true, bool reset_new_handle = false ) const

inlineprotected

dump()

void ACE_MEM_Acceptor::dump

(

)

const

Dump the state of an object.

get_local_addr()

int ACE_MEM_Acceptor::get_local_addr ( ACE_MEM_Addr & sap ) const

inline

Return the local endpoint address in the referenced <ACE_Addr>. Returns 0 if successful, else -1.

init_buffer_size()

void ACE_MEM_Acceptor::init_buffer_size ( ACE_OFF_T bytes )

inline

Change the initial MMAP buffer size (in bytes) of the MEM_Stream this MEM_Acceptor creates.

mmap_prefix() [1/2]

const ACE_TCHAR * ACE_MEM_Acceptor::mmap_prefix ( ) const

inline

Accessor/mutator of mmap filename prefix. By default, the <mmap_prefix_> is not set and the mmap filename is ${(TMP|TEMP)}//ACE_MEM_Acceptor_(port-number)_(&stream), otherwise, it is <mmap_prefix_>_(port-number)_(&stream), <mmap_prefix_> should include absolute path so the connector within the same host can located the mmap file. Example: /tmp/mmapfile.

mmap_prefix() [2/2]

void ACE_MEM_Acceptor::mmap_prefix ( const ACE_TCHAR * prefix )

inline

open() [1/3]

int ACE_MEM_Acceptor::open ( const ACE_Addr & local_sap, ACE_Protocol_Info * protocolinfo, ACE_SOCK_GROUP g, u_long flags, int reuse_addr, int protocol_family, int backlog = ACE_DEFAULT_BACKLOG, int protocol = 0 )

inlineprotected

open() [2/3]

int ACE_MEM_Acceptor::open ( const ACE_Addr & local_sap, int reuse_addr = 0, int protocol_family = PF_INET, int backlog = ACE_DEFAULT_BACKLOG, int protocol = 0 )

protected

open() [3/3]

int ACE_MEM_Acceptor::open	(	const ACE_MEM_Addr &	local_sap,
		int	reuse_addr = 0,
		int	backlog = ACE_DEFAULT_BACKLOG,
		int	protocol = 0 )

Initialize a passive-mode BSD-style acceptor socket (no QoS). local_sap is the address that we're going to listen for connections on. If reuse_addr is 1 then we'll use the SO_REUSEADDR to reuse this address. Returns 0 on success and -1 on failure.

preferred_strategy() [1/2]

ACE_MEM_IO::Signal_Strategy ACE_MEM_Acceptor::preferred_strategy ( ) const

inline

Get the preferred signaling strategy.

preferred_strategy() [2/2]

void ACE_MEM_Acceptor::preferred_strategy ( ACE_MEM_IO::Signal_Strategy strategy )

inline

Set the preferred signaling strategy.

shared_accept_finish()

int ACE_MEM_Acceptor::shared_accept_finish	(	ACE_MEM_Stream	new_stream,
		int	in_blocking_mode,
		bool	reset_new_handle ) const

Perform operations that must occur after <ACE_OS::accept> is called.

Member Data Documentation

ACE_ALLOC_HOOK_DECLARE

ACE_MEM_Acceptor::ACE_ALLOC_HOOK_DECLARE

Declare the dynamic allocation hooks.

malloc_options_

ACE_MEM_SAP::MALLOC_OPTIONS ACE_MEM_Acceptor::malloc_options_

private

A cached MALLOC_OPTIONS. MEM_Accaptor use it to create the shared mamory malloc upon every incoming connection.

mmap_prefix_

ACE_TCHAR* ACE_MEM_Acceptor::mmap_prefix_

private

The filename prefix of the created mmap files. It should contains the absolute path name of the file.

preferred_strategy_

ACE_MEM_IO::Signal_Strategy ACE_MEM_Acceptor::preferred_strategy_

private

Preferred signaling strategy.

---

The documentation for this class was generated from the following files:

• MEM_Acceptor.h
• MEM_Acceptor.cpp
• MEM_Acceptor.inl
