TAO_CEC_Reactive_ConsumerControl Class Reference

ConsumerControl. More...

#include <CEC_Reactive_ConsumerControl.h>

Inheritance diagram for TAO_CEC_Reactive_ConsumerControl:

Collaboration diagram for TAO_CEC_Reactive_ConsumerControl:

Public Member Functions
	TAO_CEC_Reactive_ConsumerControl (const ACE_Time_Value &rate, const ACE_Time_Value &timeout, unsigned int retries, TAO_CEC_EventChannel *event_channel, CORBA::ORB_ptr orb)
virtual	~TAO_CEC_Reactive_ConsumerControl ()
	Constructor for the typed ec.
void	handle_timeout (const ACE_Time_Value &tv, const void *arg)
	Receive the timeout from the adapter.
virtual int	activate ()
virtual int	shutdown ()
virtual void	consumer_not_exist (TAO_CEC_ProxyPushSupplier *proxy)
virtual void	consumer_not_exist (TAO_CEC_ProxyPullSupplier *proxy)
virtual void	system_exception (TAO_CEC_ProxyPushSupplier *proxy, CORBA::SystemException &)
	Some system exception was rasied while trying to push an event.
virtual bool	need_to_disconnect (PortableServer::ServantBase *proxy)
virtual void	successful_transmission (PortableServer::ServantBase *proxy)
	Allow others to inform us when a send or receive was successful.
Public Member Functions inherited from TAO_CEC_ConsumerControl
	TAO_CEC_ConsumerControl ()
	Constructor.
virtual	~TAO_CEC_ConsumerControl ()
	Destructor.

Private Member Functions
void	query_consumers ()

Private Attributes
ACE_Time_Value	rate_
	The polling rate.
ACE_Time_Value	timeout_
	The polling timeout.
unsigned int	retries_
	The number of retries per proxy until it is disconnected.
TAO_CEC_ConsumerControl_Adapter	adapter_
	The Adapter for the reactor events.
TAO_CEC_EventChannel *	event_channel_
	The event channel.
CORBA::ORB_var	orb_
	The typed event channel.
CORBA::PolicyCurrent_var	policy_current_
	To control the timeout policy in the thread.
CORBA::PolicyList	policy_list_
	Precomputed policy list to the set timeout.
ACE_Reactor *	reactor_
	The ORB reactor.

Detailed Description

ConsumerControl.

Defines the interface for the consumer control strategy. This strategy handles misbehaving or failing consumers. = MEMORY MANAGEMENT = LOCKING = TODO

Constructor & Destructor Documentation

TAO_CEC_Reactive_ConsumerControl()

TAO_CEC_Reactive_ConsumerControl::TAO_CEC_Reactive_ConsumerControl	(	const ACE_Time_Value &	rate,
		const ACE_Time_Value &	timeout,
		unsigned int	retries,
		TAO_CEC_EventChannel *	event_channel,
		CORBA::ORB_ptr	orb )

Constructor. It does not assume ownership of the event_channel parameter.

~TAO_CEC_Reactive_ConsumerControl()

TAO_CEC_Reactive_ConsumerControl::~TAO_CEC_Reactive_ConsumerControl ( )

virtual

Constructor for the typed ec.

destructor...

Member Function Documentation

activate()

int TAO_CEC_Reactive_ConsumerControl::activate ( )

virtual

Activate any internal threads or timers used to poll the state of the consumers

Reimplemented from TAO_CEC_ConsumerControl.

consumer_not_exist() [1/2]

void TAO_CEC_Reactive_ConsumerControl::consumer_not_exist ( TAO_CEC_ProxyPullSupplier * proxy )

virtual

Invoked by helper classes when they detect that a consumer no longer exists (i.e. _non_existent() returns true and/or the CORBA::OBJECT_NOT_EXIST exception has been raised).

Reimplemented from TAO_CEC_ConsumerControl.

consumer_not_exist() [2/2]

void TAO_CEC_Reactive_ConsumerControl::consumer_not_exist ( TAO_CEC_ProxyPushSupplier * proxy )

virtual

When pushing an event to the consumer a CORBA::OBJECT_NOT_EXIST exception was raised. The only interpretation is that the object has been destroyed. The strategy has to (at the very least), reclaim all the resources attached to that object.

Reimplemented from TAO_CEC_ConsumerControl.

handle_timeout()

void TAO_CEC_Reactive_ConsumerControl::handle_timeout	(	const ACE_Time_Value &	tv,
		const void *	arg )

Receive the timeout from the adapter.

need_to_disconnect()

bool TAO_CEC_Reactive_ConsumerControl::need_to_disconnect ( PortableServer::ServantBase * proxy )

virtual

Do we need to disconnect this supplier? The parameter type for proxy is PortableServer::ServantBase* due to the fact that this method will be used for TAO_CEC_ProxyPushSupplier's and TAO_CEC_ProxyPullSupplier's.

Reimplemented from TAO_CEC_ConsumerControl.

query_consumers()

void TAO_CEC_Reactive_ConsumerControl::query_consumers ( )

private

Check if the consumers still exists. It is a helper method for handle_timeout() to isolate the exceptions.

shutdown()

int TAO_CEC_Reactive_ConsumerControl::shutdown ( )

virtual

Reimplemented from TAO_CEC_ConsumerControl.

successful_transmission()

void TAO_CEC_Reactive_ConsumerControl::successful_transmission ( PortableServer::ServantBase * proxy )

virtual

Allow others to inform us when a send or receive was successful.

Reimplemented from TAO_CEC_ConsumerControl.

system_exception()

void TAO_CEC_Reactive_ConsumerControl::system_exception ( TAO_CEC_ProxyPushSupplier * proxy, CORBA::SystemException &  )

virtual

Some system exception was rasied while trying to push an event.

Reimplemented from TAO_CEC_ConsumerControl.

Member Data Documentation

adapter_

TAO_CEC_ConsumerControl_Adapter TAO_CEC_Reactive_ConsumerControl::adapter_

private

The Adapter for the reactor events.

event_channel_

TAO_CEC_EventChannel* TAO_CEC_Reactive_ConsumerControl::event_channel_

private

The event channel.

orb_

CORBA::ORB_var TAO_CEC_Reactive_ConsumerControl::orb_

private

The typed event channel.

The ORB

policy_current_

CORBA::PolicyCurrent_var TAO_CEC_Reactive_ConsumerControl::policy_current_

private

To control the timeout policy in the thread.

policy_list_

CORBA::PolicyList TAO_CEC_Reactive_ConsumerControl::policy_list_

private

Precomputed policy list to the set timeout.

rate_

ACE_Time_Value TAO_CEC_Reactive_ConsumerControl::rate_

private

The polling rate.

reactor_

ACE_Reactor* TAO_CEC_Reactive_ConsumerControl::reactor_

private

The ORB reactor.

retries_

unsigned int TAO_CEC_Reactive_ConsumerControl::retries_

private

The number of retries per proxy until it is disconnected.

timeout_

ACE_Time_Value TAO_CEC_Reactive_ConsumerControl::timeout_

private

The polling timeout.

---

The documentation for this class was generated from the following files:

• CEC_Reactive_ConsumerControl.h
• CEC_Reactive_ConsumerControl.cpp
